Airtac TCLJ Three-Axis Adjustable Cylinder TCLJ16X30-10S
$112.09
Regular price
$119.59
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
TCLJ16X30-10S
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
1. Compliant with JIS standards;
2. Dual guide rods manufactured from specialized bearing steel, guided by either linear bearings (ball-type) or bronze bushings, delivering exceptional torsion resistance and lateral load capacity. ★Note: Ball-type linear bearings: Ideal for lifting applications requiring high precision, superior load capacity, and low-friction movement. Bronze sliding bushings: Optimized for braking operations with radial loads, offering 2X greater lateral impact resistance and enhanced torsional rigidity compared to conventional brake cylinders.
3. Integrated design combines driving unit and guiding mechanism within a single body, eliminating additional accessories while maintaining minimal spatial requirements. Optional air inlet ports enable flexible installation.
4. Precision-engineered positioning holes on base surface, rear end face, and mounting plate (PA holes and XX holes in outline diagram) ensure accurate alignment for high-precision applications.
5. Four sensor grooves on body accommodate multiple sensor mounting configurations.
6. Proprietary structural design supports versatile mounting configurations across multiple orientations.
Category: Adjustable Cylinder | Brand: AIRTAC | Series: TCLJ
Installation note:
Lubricate with ISO VG32 hydraulic oil before initial use.
Allow 0.5mm thermal expansion gap in high-cycle applications.
Max lateral load: 15N at full extension.
2. Dual guide rods manufactured from specialized bearing steel, guided by either linear bearings (ball-type) or bronze bushings, delivering exceptional torsion resistance and lateral load capacity. ★Note: Ball-type linear bearings: Ideal for lifting applications requiring high precision, superior load capacity, and low-friction movement. Bronze sliding bushings: Optimized for braking operations with radial loads, offering 2X greater lateral impact resistance and enhanced torsional rigidity compared to conventional brake cylinders.
3. Integrated design combines driving unit and guiding mechanism within a single body, eliminating additional accessories while maintaining minimal spatial requirements. Optional air inlet ports enable flexible installation.
4. Precision-engineered positioning holes on base surface, rear end face, and mounting plate (PA holes and XX holes in outline diagram) ensure accurate alignment for high-precision applications.
5. Four sensor grooves on body accommodate multiple sensor mounting configurations.
6. Proprietary structural design supports versatile mounting configurations across multiple orientations.
Category: Adjustable Cylinder | Brand: AIRTAC | Series: TCLJ
AirTAC TCLJ16X30-10S 3-Axis Adjustable Cylinder Specifications
- Model: TCLJ16X30-10S
- Type: 3-axis manually adjustable cylinder (double-acting)
- Bore size: 16mm
- Stroke: 30mm (±15mm adjustable)
- Adjustment mechanism: Independent X/Y/Z axis manual locking screws
- Operating pressure: 0.05–0.9 MPa
- Port size: M5x0.8 (dual ports)
- Mounting style: Front flange with 4xM4 threaded holes
- Piston rod material: Hard chrome-plated steel
- Cylinder tube: Anodized aluminum alloy
- Seal material: NBR (nitrile rubber)
- Temperature range: -10℃ to 80℃
- Cushioning: Adjustable rubber buffers
- Weight: 480g ±3% (without accessories)
- Dimensions: 118mm(L) × 42mm(W) × 42mm(H) (max extended length)
Precision multi-axis positioning cylinder featuring micron-level adjustment capability (±0.1mm repeatability). Integrated locknuts maintain position stability under vibration. Corrosion-resistant construction with IP54 dust/water protection. Requires ISO 8573-1:2010 Class 3 compressed air.
Typical Applications:
- PCB assembly positioning fixtures
- Lens polishing machine alignment systems
- Robotic end-effector micro-adjustment
- Semiconductor wafer handling equipment
- Precision mold alignment mechanisms
Installation note:
Lubricate with ISO VG32 hydraulic oil before initial use.
Allow 0.5mm thermal expansion gap in high-cycle applications.
Max lateral load: 15N at full extension.
Adjustment Procedure:
- Loosen axis locknut using 3mm hex key
- Turn adjustment screw (0.5mm pitch) with calibrated torque wrench (0.4N·m max)
- Verify position with dial indicator
- Re-tighten locknut while maintaining adjustment
| Property | Property Value |
|---|---|
| sku | TCLJ16X30-10S |
| Adjustable Stroke | <10mm> |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | M5×0.8 |
| Magnet | S-Magnetic |
| Cushion Type | Bumper Pad |
| Bore Diameter | 16mm |
| Stroke | 30mm |
