Airtac TCLJ Three-Axis Adjustable Cylinder TCLJ16X30-20S
$112.09
Regular price
$119.59
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
TCLJ16X30-20S
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
1. Compliant with JIS standards;
2. Dual guide rods manufactured from specialized bearing steel, guided by either linear bearings (ball-type) or bronze bushings, delivering exceptional torsion resistance and lateral load capacity. ★Note: Ball-type linear bearings: Ideal for lifting applications requiring high precision, superior load capacity, and low-friction movement. Bronze sliding bushings: Optimized for braking operations with radial loads, offering 2X greater lateral impact resistance and enhanced torsional rigidity compared to conventional brake cylinders.
3. Integrated design combines driving unit and guiding mechanism within a single body, eliminating additional accessories while maintaining minimal spatial requirements. Optional air inlet ports enable flexible installation.
4. Precision-engineered positioning holes on base surface, rear end face, and mounting plate (PA holes and XX holes in outline diagram) ensure accurate alignment for high-precision applications.
5. Four sensor grooves on body accommodate multiple sensor mounting configurations.
6. Proprietary structural design supports versatile mounting configurations across multiple orientations.
Category: Adjustable Cylinder | Brand: AIRTAC | Series: TCLJ
Installation note:
Always degrease adjustment screws before first use. Perform axis alignment verification after installation using dial indicator (recommended tolerance ≤0.05mm). Maintain 0.5-1mm free play in adjustment mechanism to prevent over-constraint.
Maintenance alert:
Re-lubricate every 500,000 cycles or 6 months in high-humidity environments. Avoid using silicone-based lubricants which may degrade NBR seals.
2. Dual guide rods manufactured from specialized bearing steel, guided by either linear bearings (ball-type) or bronze bushings, delivering exceptional torsion resistance and lateral load capacity. ★Note: Ball-type linear bearings: Ideal for lifting applications requiring high precision, superior load capacity, and low-friction movement. Bronze sliding bushings: Optimized for braking operations with radial loads, offering 2X greater lateral impact resistance and enhanced torsional rigidity compared to conventional brake cylinders.
3. Integrated design combines driving unit and guiding mechanism within a single body, eliminating additional accessories while maintaining minimal spatial requirements. Optional air inlet ports enable flexible installation.
4. Precision-engineered positioning holes on base surface, rear end face, and mounting plate (PA holes and XX holes in outline diagram) ensure accurate alignment for high-precision applications.
5. Four sensor grooves on body accommodate multiple sensor mounting configurations.
6. Proprietary structural design supports versatile mounting configurations across multiple orientations.
Category: Adjustable Cylinder | Brand: AIRTAC | Series: TCLJ
AirTAC TCLJ16X30-20S 3-Axis Adjustable Cylinder Specifications
- Model: TCLJ16X30-20S
- Type: 3-axis adjustable compact cylinder (double-acting)
- Bore size: 16mm
- Stroke: 30mm (±10mm adjustable range)
- Adjustment mechanism: Hex socket screw with locking nut
- Operating pressure: 0.05-0.9 MPa
- Temperature range: -10℃ to 70℃
- Port size: M5x0.8 (dual ports)
- Mounting style: Dual through-hole (4.5mm diameter)
- Piston material: Aluminum alloy with hard anodizing
- Rod material: Stainless steel (SUS304)
- Seal type: NBR rubber (oil-resistant)
- Cushioning: Adjustable air cushion at both ends
- Weight: 0.62kg ±3%
- Dimensions: 110mm(L) × 34mm(W) × 34mm(H)
- Protection rating: IP54 (standard dust/moisture resistance)
- Lubrication: Pre-lubricated (use ISO VG32 or equivalent)
Precision triple-axis adjustable cylinder featuring micro-positioning capability through independent X/Y/Z axis adjustment screws. The chrome-plated piston rod and dual cushion design enable smooth operation in high-cycle applications. Integrated mounting grooves allow direct sensor installation for position feedback.
Typical Applications:
- PCB board clamping/fixturing in electronics assembly
- Precision alignment in optical component manufacturing
- Multi-position workpiece holding in CNC machining centers
- Adjustable stoppers in automated conveyor systems
- Micro-adjustment platforms for laboratory equipment
Installation note:
Always degrease adjustment screws before first use. Perform axis alignment verification after installation using dial indicator (recommended tolerance ≤0.05mm). Maintain 0.5-1mm free play in adjustment mechanism to prevent over-constraint.
Maintenance alert:
Re-lubricate every 500,000 cycles or 6 months in high-humidity environments. Avoid using silicone-based lubricants which may degrade NBR seals.
| Property | Property Value |
|---|---|
| sku | TCLJ16X30-20S |
| Adjustable Stroke | <20mm> |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | M5×0.8 |
| Magnet | S-Magnetic |
| Cushion Type | Bumper Pad |
| Bore Diameter | 16mm |
| Stroke | 30mm |
