Airtac TCLJ Three-Axis Adjustable Cylinder TCLJ16X80-10S
$140.94
Regular price
$148.44
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
TCLJ16X80-10S
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
1. Compliant with JIS standards;
2. Dual guide rods manufactured from specialized bearing steel, guided by either linear bearings (ball-type) or bronze bushings, delivering exceptional torsion resistance and lateral load capacity. ★Note: Ball-type linear bearings: Ideal for lifting applications requiring high precision, superior load capacity, and low-friction movement. Bronze sliding bushings: Optimized for braking operations with radial loads, offering 2X greater lateral impact resistance and enhanced torsional rigidity compared to conventional brake cylinders.
3. Integrated design combines driving unit and guiding mechanism within a single body, eliminating additional accessories while maintaining minimal spatial requirements. Optional air inlet ports enable flexible installation.
4. Precision-engineered positioning holes on base surface, rear end face, and mounting plate (PA holes and XX holes in outline diagram) ensure accurate alignment for high-precision applications.
5. Four sensor grooves on body accommodate multiple sensor mounting configurations.
6. Proprietary structural design supports versatile mounting configurations across multiple orientations.
Category: Adjustable Cylinder | Brand: AIRTAC | Series: TCLJ
Installation notes:
(1) Use locknuts on all adjustment screws after alignment.
(2) Lubricate with ISO VG32 turbine oil before initial operation.
(3) Maximum side load capacity reduces by 40% when used in vertical orientation.
2. Dual guide rods manufactured from specialized bearing steel, guided by either linear bearings (ball-type) or bronze bushings, delivering exceptional torsion resistance and lateral load capacity. ★Note: Ball-type linear bearings: Ideal for lifting applications requiring high precision, superior load capacity, and low-friction movement. Bronze sliding bushings: Optimized for braking operations with radial loads, offering 2X greater lateral impact resistance and enhanced torsional rigidity compared to conventional brake cylinders.
3. Integrated design combines driving unit and guiding mechanism within a single body, eliminating additional accessories while maintaining minimal spatial requirements. Optional air inlet ports enable flexible installation.
4. Precision-engineered positioning holes on base surface, rear end face, and mounting plate (PA holes and XX holes in outline diagram) ensure accurate alignment for high-precision applications.
5. Four sensor grooves on body accommodate multiple sensor mounting configurations.
6. Proprietary structural design supports versatile mounting configurations across multiple orientations.
Category: Adjustable Cylinder | Brand: AIRTAC | Series: TCLJ
AirTAC TCLJ16X80-10S 3-Axis Adjustable Cylinder Specifications
- Model: TCLJ16X80-10S
- Type: Triple-axis adjustable pneumatic cylinder (rodless type)
- Bore size: 16mm
- Stroke: 80mm ±0.5mm (adjustable)
- Operating pressure: 0.1–0.9 MPa
- Cushioning: Adjustable air cushion (both ends)
- Mounting style: Front/rear flange (ISO 15552 compatible)
- Port size: M5x0.8 (G1/8 adaptor available)
- Piston material: Hard-anodized aluminum alloy
- Rod material: Chrome-plated steel (Cr-Mo alloy)
- Seals: NBR (nitrile) standard, optional FKM/Viton
- Temperature range: -20℃ to 80℃ (with standard seals)
- Weight: 0.65kg ±3% (without accessories)
- Dimensions: 180mm(L) × 32mm(W) × 32mm(H)
- Repeat accuracy: ±0.2mm
- Max lateral load: 12N (at full extension)
- ISO standard: 15552 (formerly ISO 6431)
Precision triple-axis cylinder with 360° adjustable mounting points and micrometer-style stroke adjustment (1mm/division). Features dual piston guides for anti-rotation stability and integrated T-slot mounting channels. Includes shock-absorbing bumpers and wear-resistant scraper rings. Compatible with ATEX Zone 2 environments when ordered with FKM seals.
Typical Applications:
- PCB board positioning in SMT assembly lines
- Multi-angle clamping in CNC fixture systems
- Precision material transfer in pharmaceutical blister packaging
- 3D sensor alignment in automotive inspection jigs
- Compact robotic end-effector positioning
Installation notes:
(1) Use locknuts on all adjustment screws after alignment.
(2) Lubricate with ISO VG32 turbine oil before initial operation.
(3) Maximum side load capacity reduces by 40% when used in vertical orientation.
Common Accessories:
- Magnetic sensor kit: TCLJ-M12D4 (IP67 rated)
- Rod-end alignment coupler: TCLJ-RAC16
- Heat-resistant variant: TCLJ16X80-10S-H (150℃ max)
| Property | Property Value |
|---|---|
| sku | TCLJ16X80-10S |
| Adjustable Stroke | <10mm> |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | M5×0.8 |
| Magnet | S-Magnetic |
| Cushion Type | Bumper Pad |
| Bore Diameter | 16mm |
| Stroke | 80 mm |
