Airtac TCM Triple Axis Cylinder TCM50X70-S
$168.24
Regular price
$175.74
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
TCM50X70-S
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
1. Complies with JIS standards;
2. Features two guide rods manufactured from specialized bearing steel, guided by linear ball bearings or bronze sliding bearings, delivering exceptional torsion resistance and lateral load capacity. ★Note: Linear ball bearings: Ideal for thrust applications requiring high precision, heavy payloads, and low-friction motion. Bronze sliding bearings: Optimized for radial load applications like braking systems, offering 2X greater lateral impact resistance and enhanced torsional rigidity compared to standard brake cylinders;
3. Integrated design combines driving unit and guidance mechanism within a single body, eliminating need for auxiliary components. Features minimal spatial footprint with configurable intake ports for flexible installation;
4. Precision positioning holes on base surface (2x), rear face (2x), and mounting plate (2x at PA/XX locations) ensure accurate alignment. Enhanced precision variants available for critical positioning requirements;
5. Four strategically engineered magnetic sensor grooves on body enable multiple switch mounting configurations;
6. Modular body architecture supports multi-orientation mounting solutions;
Category: Three-axis guided cylinders | Brand: AirTAC | Series: TCM
Installation note:
Align guide rails within 0.05mm/m parallelism tolerance. Use flexible couplings
when connecting to driven components. For vertical mounting, install air vents
upward and apply 0.02 MPa minimum back pressure to prevent piston drift.
2. Features two guide rods manufactured from specialized bearing steel, guided by linear ball bearings or bronze sliding bearings, delivering exceptional torsion resistance and lateral load capacity. ★Note: Linear ball bearings: Ideal for thrust applications requiring high precision, heavy payloads, and low-friction motion. Bronze sliding bearings: Optimized for radial load applications like braking systems, offering 2X greater lateral impact resistance and enhanced torsional rigidity compared to standard brake cylinders;
3. Integrated design combines driving unit and guidance mechanism within a single body, eliminating need for auxiliary components. Features minimal spatial footprint with configurable intake ports for flexible installation;
4. Precision positioning holes on base surface (2x), rear face (2x), and mounting plate (2x at PA/XX locations) ensure accurate alignment. Enhanced precision variants available for critical positioning requirements;
5. Four strategically engineered magnetic sensor grooves on body enable multiple switch mounting configurations;
6. Modular body architecture supports multi-orientation mounting solutions;
Category: Three-axis guided cylinders | Brand: AirTAC | Series: TCM
AirTAC TCM50X70-S Triple Axis Cylinder Specifications
- Model: TCM50X70-S
- Type: Triple-axis compact guided cylinder (ISO 15552 compliant)
- Bore size: Ø50 mm
- Stroke: 70 mm (±0.5 mm tolerance)
- Operating pressure: 0.05–1.0 MPa
- Piston speed: 50–700 mm/s (cushioned)
- Max thrust: 1,963 N @ 0.63 MPa (both chambers pressurized)
- Port size: Rc1/4 (G1/4 optional)
- Mounting: ISO mounting grooves + side mounting holes
- Rod material: Hard chrome-plated steel (S45C)
- Tube material: Anodized aluminum alloy
- Seal material: NBR + PU combination
- Temperature range: -20℃ to 80℃ (dry air required below 0℃)
- Weight: 2.8 kg (without accessories)
- Dimensions: 206mm(L) × 62mm(W) × 62mm(H) (fully retracted)
- Repeat accuracy: ±0.1 mm
- Cushion type: Adjustable hydraulic shock absorber
- Protection rating: IP54 (standard), IP67 with optional wipers
- Lubrication: Pre-lubricated (Oil-free operation possible with special seals)
High-precision triple-axis cylinder with integrated linear guides, designed for complex multi-directional positioning. Features dual piston rods and anti-rotation mechanism for enhanced moment resistance (max 18 N·m). The T-shaped base allows vertical/horizontal mounting with optional auto-switch compatibility (slot-in type). Requires 5μm filtered air with ≤1 mg/m³ oil content.
Typical Applications:
- PCB handling robots with Z-axis rotation
- Automated optical inspection (AOI) positioning stages
- Precision welding equipment with XYZ compensation
- Semiconductor wafer transfer systems
- Multi-station rotary index table drives
Installation note:
Align guide rails within 0.05mm/m parallelism tolerance. Use flexible couplings
when connecting to driven components. For vertical mounting, install air vents
upward and apply 0.02 MPa minimum back pressure to prevent piston drift.
| Property | Property Value |
|---|---|
| sku | TCM50X70-S |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | PT1/4 |
| Magnet | S-Magnetic |
| Cushion Type | Bumper Pad |
| Bore Diameter | <50mm> |
| Stroke | 70mm |
| Bearing Code | Bronze Bushing |
