Airtac TCM Triple Axis Cylinder TCM50X80-S
$172.89
Regular price
$180.39
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
TCM50X80-S
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
1. Complies with JIS standards;
2. Features two guide rods manufactured from specialized bearing steel, guided by linear ball bearings or bronze sliding bearings, delivering exceptional torsion resistance and lateral load capacity. ★Note: Linear ball bearings: Ideal for thrust applications requiring high precision, heavy payloads, and low-friction motion. Bronze sliding bearings: Optimized for radial load applications like braking systems, offering 2X greater lateral impact resistance and enhanced torsional rigidity compared to standard brake cylinders;
3. Integrated design combines driving unit and guidance mechanism within a single body, eliminating need for auxiliary components. Features minimal spatial footprint with configurable intake ports for flexible installation;
4. Precision positioning holes on base surface (2x), rear face (2x), and mounting plate (2x at PA/XX locations) ensure accurate alignment. Enhanced precision variants available for critical positioning requirements;
5. Four strategically engineered magnetic sensor grooves on body enable multiple switch mounting configurations;
6. Modular body architecture supports multi-orientation mounting solutions;
Category: Three-axis guided cylinders | Brand: AirTAC | Series: TCM
Installation note:
Use grade 12.9 mounting bolts with 28±2 N·m torque. Requires
simultaneous 3-axis alignment during installation.
Recommend using M4x0.7 pilot screws for guide rail adjustment.
2. Features two guide rods manufactured from specialized bearing steel, guided by linear ball bearings or bronze sliding bearings, delivering exceptional torsion resistance and lateral load capacity. ★Note: Linear ball bearings: Ideal for thrust applications requiring high precision, heavy payloads, and low-friction motion. Bronze sliding bearings: Optimized for radial load applications like braking systems, offering 2X greater lateral impact resistance and enhanced torsional rigidity compared to standard brake cylinders;
3. Integrated design combines driving unit and guidance mechanism within a single body, eliminating need for auxiliary components. Features minimal spatial footprint with configurable intake ports for flexible installation;
4. Precision positioning holes on base surface (2x), rear face (2x), and mounting plate (2x at PA/XX locations) ensure accurate alignment. Enhanced precision variants available for critical positioning requirements;
5. Four strategically engineered magnetic sensor grooves on body enable multiple switch mounting configurations;
6. Modular body architecture supports multi-orientation mounting solutions;
Category: Three-axis guided cylinders | Brand: AirTAC | Series: TCM
AirTAC TCM50X80-S Triple Axis Cylinder Specifications
- Model: TCM50X80-S
- Type: Compact triple-axis guided cylinder (X/Y/Z motion)
- Bore size: Ø50mm
- Stroke: 80mm (standard), customizable up to 300mm
- Operating pressure: 0.1–0.9 MPa
- Piston speed: 50–800 mm/s
- Cushioning: Adjustable rubber buffer + shock absorber
- Mounting type: Front flange with precision alignment pins
- Rod material: Hard chrome-plated steel (HRC 45+)
- Seal type: NBR + special wear-resistant ring
- Temperature range: -10℃ to 100℃
- Weight: 3.8kg (without accessories)
- Dimensions: 185mm(L) × 100mm(W) × 105mm(H)
- Position repeatability: ±0.05mm
- Lubrication: Pre-lubed (Grease-free operation available)
High-precision triple-axis cylinder with integrated linear guides, designed for complex multi-directional positioning in automated systems. Features hardened guide rails with 4-row ball bearing system for minimal deflection (≤0.01mm/100mm). Anti-vibration design withstands lateral forces up to 800N.
Typical Applications:
- PCB component insertion machines
- Automated optical inspection (AOI) systems
- Precision welding robot end effectors
- Semiconductor wafer handling
- Multi-axis dispensing/pick-and-place units
Installation note:
Use grade 12.9 mounting bolts with 28±2 N·m torque. Requires
simultaneous 3-axis alignment during installation.
Recommend using M4x0.7 pilot screws for guide rail adjustment.
Maintenance cycle:
Relubricate guide rails every 500km of travel or 6 months with
ISO VG32 hydraulic oil (2ml per rail). Monitor wear indicators
on side plates for guide replacement timing.
| Property | Property Value |
|---|---|
| sku | TCM50X80-S |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | PT1/4 |
| Magnet | S-Magnetic |
| Cushion Type | Bumper Pad |
| Bore Diameter | <50mm> |
| Stroke | 80 mm |
| Bearing Code | Bronze Bushing |
