Airtac TCM Triple Axis Cylinder TCM63X30-S
$163.07
Regular price
$170.57
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
TCM63X30-S
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
1. Complies with JIS standards;
2. Features two guide rods manufactured from specialized bearing steel, guided by linear ball bearings or bronze sliding bearings, delivering exceptional torsion resistance and lateral load capacity. ★Note: Linear ball bearings: Ideal for thrust applications requiring high precision, heavy payloads, and low-friction motion. Bronze sliding bearings: Optimized for radial load applications like braking systems, offering 2X greater lateral impact resistance and enhanced torsional rigidity compared to standard brake cylinders;
3. Integrated design combines driving unit and guidance mechanism within a single body, eliminating need for auxiliary components. Features minimal spatial footprint with configurable intake ports for flexible installation;
4. Precision positioning holes on base surface (2x), rear face (2x), and mounting plate (2x at PA/XX locations) ensure accurate alignment. Enhanced precision variants available for critical positioning requirements;
5. Four strategically engineered magnetic sensor grooves on body enable multiple switch mounting configurations;
6. Modular body architecture supports multi-orientation mounting solutions;
Category: Three-axis guided cylinders | Brand: AirTAC | Series: TCM
Installation protocol:
Maintain 0.05mm/m alignment tolerance during mounting. Apply initial lubrication (ISO VG32)
to rod ends before operation. Avoid side load exceeding 10% of maximum thrust capacity.
2. Features two guide rods manufactured from specialized bearing steel, guided by linear ball bearings or bronze sliding bearings, delivering exceptional torsion resistance and lateral load capacity. ★Note: Linear ball bearings: Ideal for thrust applications requiring high precision, heavy payloads, and low-friction motion. Bronze sliding bearings: Optimized for radial load applications like braking systems, offering 2X greater lateral impact resistance and enhanced torsional rigidity compared to standard brake cylinders;
3. Integrated design combines driving unit and guidance mechanism within a single body, eliminating need for auxiliary components. Features minimal spatial footprint with configurable intake ports for flexible installation;
4. Precision positioning holes on base surface (2x), rear face (2x), and mounting plate (2x at PA/XX locations) ensure accurate alignment. Enhanced precision variants available for critical positioning requirements;
5. Four strategically engineered magnetic sensor grooves on body enable multiple switch mounting configurations;
6. Modular body architecture supports multi-orientation mounting solutions;
Category: Three-axis guided cylinders | Brand: AirTAC | Series: TCM
AirTAC TCM63X30-S Triple Axis Cylinder Technical Details
- Model: TCM63X30-S
- Type: Triple-axis compact cylinder (double-acting)
- Bore size: Ø63mm
- Stroke: 30mm (customizable up to 300mm)
- Operating pressure: 0.15–0.8 MPa
- Cushioning: Adjustable pneumatic cushion
- Mounting styles: MF1/MF2 flange, MA1/MA2 side lug
- Material:
- Tube: Aluminum alloy (hard anodized)
- Piston rod: Stainless steel (SUS304)
- Seals: NBR + PU hybrid
- Weight: 2.8kg ±3% (without accessories)
- Dimensions: 250mm(L) × 120mm(W) × 125mm(H)
- Temperature range: -20℃ to 80℃
- Max speed: 500–800mm/s (lubricated)
- Protection rating: IP65 (standard), IP67 optional
- Piston rod thread: M12×1.25 (ISO standard)
Precision-engineered triple-axis cylinder with integrated guide mechanism, featuring ultra-low friction and anti-rotation stability. The TCM series employs dual piston rods and linear ball bearings for enhanced moment load capacity (up to 15N·m). Includes magnetic piston for position sensing compatibility. Requires ISO VG32 hydraulic oil mist lubrication for optimal performance.
Industrial Applications:
- Multi-axis positioning in robotic welding stations
- Precision alignment systems for PCB assembly
- Vertical Z-axis drives in CNC tool changers
- Automated palletizing systems with guided descent
- Glass panel handling with anti-twist requirements
Installation protocol:
Maintain 0.05mm/m alignment tolerance during mounting. Apply initial lubrication (ISO VG32)
to rod ends before operation. Avoid side load exceeding 10% of maximum thrust capacity.
Critical Notice:
Requires 5μm filtration for compressed air. For vertical installations,
always use counterbalance valves when handling suspended loads.
| Property | Property Value |
|---|---|
| sku | TCM63X30-S |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | PT1/4 |
| Magnet | S-Magnetic |
| Cushion Type | Bumper Pad |
| Bore Diameter | 63mm |
| Stroke | 30mm |
| Bearing Code | Bronze Bushing |
