Airtac TCMJ Three-Axis Adjustable Cylinder TCMJ100X25-20S
$411.27
Regular price
$418.77
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
TCMJ100X25-20S
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
1. Complies with JIS standards;
2. Dual guide rods manufactured from specialized bearing steel, guided by linear ball bearings or bronze sliding bearings, delivering exceptional resistance to torsion and lateral loads.★Note: Linear ball bearings: Ideal for lifting applications requiring high precision, heavy load capacity, and low-friction movement. Bronze sliding bearings: Specially engineered for radial load applications like braking systems, offering over twice the lateral impact resistance of standard brake cylinders with enhanced torsional rigidity.
3. Integrated design combines driving unit and guiding mechanism within a single body, eliminating additional accessories while providing compact dimensions and adjustable intake ports for flexible installation;
4. Precision positioning holes on base surface, rear end face, and mounting plate (refer to PA holes and XX marked holes in outline drawing) ensure high-accuracy alignment for critical applications;
5. Four sensor grooves on body enable multiple sensor mounting configurations;
6. Proprietary body structure supports multi-orientation mounting solutions;
Category: Adjustable Cylinders | Brand: AIRTAC | Series: TCMJ
Installation protocol:
Always perform axis alignment verification using dial indicators after installation.
Lubricate adjustment screws with ISO VG32 pneumatic oil monthly.
Maximum side load: 300N at full extension.
2. Dual guide rods manufactured from specialized bearing steel, guided by linear ball bearings or bronze sliding bearings, delivering exceptional resistance to torsion and lateral loads.★Note: Linear ball bearings: Ideal for lifting applications requiring high precision, heavy load capacity, and low-friction movement. Bronze sliding bearings: Specially engineered for radial load applications like braking systems, offering over twice the lateral impact resistance of standard brake cylinders with enhanced torsional rigidity.
3. Integrated design combines driving unit and guiding mechanism within a single body, eliminating additional accessories while providing compact dimensions and adjustable intake ports for flexible installation;
4. Precision positioning holes on base surface, rear end face, and mounting plate (refer to PA holes and XX marked holes in outline drawing) ensure high-accuracy alignment for critical applications;
5. Four sensor grooves on body enable multiple sensor mounting configurations;
6. Proprietary body structure supports multi-orientation mounting solutions;
Category: Adjustable Cylinders | Brand: AIRTAC | Series: TCMJ
AirTAC TCMJ100X25-20S 3-Axis Adjustable Cylinder Technical Details
- Model: TCMJ100X25-20S
- Type: Triple-axis adjustable cylinder (body adjustable type)
- Bore size: Ø100mm
- Stroke: 25mm (adjustable through external stopper)
- Operating pressure: 0.05-1.0 MPa
- Piston speed: 50-700mm/s (with cushioning)
- Ambient temperature: -20℃ to 80℃
- Mounting type: Standard ISO 15552 foot-mount with 20mm adjustment slots
- Rod end: Female thread M20×1.5
- Material: Aluminum alloy body, chrome-plated piston rod
- Seal type: NBR seals (optional FKM for high temp)
- Weight: 5.8kg (without accessories)
- Dimensions: 330mm(L) × 150mm(W) × 150mm(H) (fully extended)
- Adjustment range: ±2° in X/Y/Z axes
- Repeat positioning accuracy: ±0.2mm
- Air port size: G3/8
Precision triple-axis alignment cylinder featuring micrometer-style adjustment screws (0.01mm graduation) for fine positioning. The TCMJ series incorporates dual shock absorbers and wear-resistant guide bushings, delivering 50% higher lateral load capacity than standard cylinders. Requires clean compressed air with 5-40μm filtration.
Industrial Applications:
- Automated optical inspection (AOI) equipment alignment
- PCB drilling machine Z-axis compensation
- Robotic welding gun positioning systems
- Precision mold clamping force adjustment
- Semiconductor wafer handling robots
Installation protocol:
Always perform axis alignment verification using dial indicators after installation.
Lubricate adjustment screws with ISO VG32 pneumatic oil monthly.
Maximum side load: 300N at full extension.
| Property | Property Value |
|---|---|
| sku | TCMJ100X25-20S |
| Adjustable Stroke | <20mm> |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20-70°C Speed Range: 50-400mm/s |
| Port Size | PT3/8 |
| Magnet | S-Magnetic |
| Cushion Type | Bumper Pad |
| Bore Diameter | 100mm |
| Stroke | <25 mm> |
