Airtac TCMJ Three-Axis Adjustable Cylinder TCMJ12X30-10S
$80.71
Regular price
$88.21
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
TCMJ12X30-10S
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
1. Complies with JIS standards;
2. Dual guide rods manufactured from specialized bearing steel, guided by linear ball bearings or bronze sliding bearings, delivering exceptional resistance to torsion and lateral loads.★Note: Linear ball bearings: Ideal for lifting applications requiring high precision, heavy load capacity, and low-friction movement. Bronze sliding bearings: Specially engineered for radial load applications like braking systems, offering over twice the lateral impact resistance of standard brake cylinders with enhanced torsional rigidity.
3. Integrated design combines driving unit and guiding mechanism within a single body, eliminating additional accessories while providing compact dimensions and adjustable intake ports for flexible installation;
4. Precision positioning holes on base surface, rear end face, and mounting plate (refer to PA holes and XX marked holes in outline drawing) ensure high-accuracy alignment for critical applications;
5. Four sensor grooves on body enable multiple sensor mounting configurations;
6. Proprietary body structure supports multi-orientation mounting solutions;
Category: Adjustable Cylinders | Brand: AIRTAC | Series: TCMJ
Installation note:
Lock adjustment screws with 0.3N·m torque after alignment. Maintain 0.5mm minimum
parallel tolerance between rod and load direction. Perform axis recalibration every
50,000 cycles or 6 months.
2. Dual guide rods manufactured from specialized bearing steel, guided by linear ball bearings or bronze sliding bearings, delivering exceptional resistance to torsion and lateral loads.★Note: Linear ball bearings: Ideal for lifting applications requiring high precision, heavy load capacity, and low-friction movement. Bronze sliding bearings: Specially engineered for radial load applications like braking systems, offering over twice the lateral impact resistance of standard brake cylinders with enhanced torsional rigidity.
3. Integrated design combines driving unit and guiding mechanism within a single body, eliminating additional accessories while providing compact dimensions and adjustable intake ports for flexible installation;
4. Precision positioning holes on base surface, rear end face, and mounting plate (refer to PA holes and XX marked holes in outline drawing) ensure high-accuracy alignment for critical applications;
5. Four sensor grooves on body enable multiple sensor mounting configurations;
6. Proprietary body structure supports multi-orientation mounting solutions;
Category: Adjustable Cylinders | Brand: AIRTAC | Series: TCMJ
AirTAC TCMJ12X30-10S 3-Axis Adjustable Cylinder Specifications
- Model: TCMJ12X30-10S
- Type: 3-axis adjustable compact cylinder (double-acting)
- Bore size: 12mm
- Stroke: 30mm
- Adjustment range: ±2mm (X/Y/Z axes via hex socket screws)
- Operating pressure: 0.1–0.9 MPa
- Temperature range: -10℃ to 70℃
- Port size: M5x0.8 (dual ports)
- Mounting style: 2x M4 threaded holes (base mounting)
- Material: Aluminum alloy body, stainless steel rod
- Cushioning: Rubber buffer (adjustable)
- Repeat positioning accuracy: ±0.1mm
- Max speed: 500mm/s
- Weight: 0.52kg (with accessories)
- Dimensions: 76mm(L) × 34mm(W) × 34mm(H) (excluding rod extension)
Precision micro-adjustment cylinder featuring triple-axis (XYZ) positional tuning capability through integrated set screws. Nickel-plated rod resists corrosion in humid environments. Integrated cushioning adjustment minimizes end-impact vibration. Requires 40μm filtered air with ISO VG32 hydraulic oil mist lubrication.
Typical Applications:
- PCB component insertion machines
- Lens positioning in optical manufacturing
- Robotic end-effector alignment systems
- Semiconductor wafer handling equipment
- Precision jig calibration devices
Installation note:
Lock adjustment screws with 0.3N·m torque after alignment. Maintain 0.5mm minimum
parallel tolerance between rod and load direction. Perform axis recalibration every
50,000 cycles or 6 months.
| Property | Property Value |
|---|---|
| sku | TCMJ12X30-10S |
| Adjustable Stroke | <10mm> |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | M5×0.8 |
| Magnet | S-Magnetic |
| Cushion Type | Bumper Pad |
| Bore Diameter | 12mm |
| Stroke | 30mm |
