Airtac TCMJ Three-Axis Adjustable Cylinder TCMJ12X40-10S
$84.44
Regular price
$91.94
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
TCMJ12X40-10S
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
1. Complies with JIS standards;
2. Dual guide rods manufactured from specialized bearing steel, guided by linear ball bearings or bronze sliding bearings, delivering exceptional resistance to torsion and lateral loads.★Note: Linear ball bearings: Ideal for lifting applications requiring high precision, heavy load capacity, and low-friction movement. Bronze sliding bearings: Specially engineered for radial load applications like braking systems, offering over twice the lateral impact resistance of standard brake cylinders with enhanced torsional rigidity.
3. Integrated design combines driving unit and guiding mechanism within a single body, eliminating additional accessories while providing compact dimensions and adjustable intake ports for flexible installation;
4. Precision positioning holes on base surface, rear end face, and mounting plate (refer to PA holes and XX marked holes in outline drawing) ensure high-accuracy alignment for critical applications;
5. Four sensor grooves on body enable multiple sensor mounting configurations;
6. Proprietary body structure supports multi-orientation mounting solutions;
Category: Adjustable Cylinders | Brand: AIRTAC | Series: TCMJ
Maintenance tip: Clean adjustment threads monthly using compressed air and apply PTFE-based lubricant (e.g., SUPER LUBE 21030) to sliding surfaces every 500,000 cycles.
2. Dual guide rods manufactured from specialized bearing steel, guided by linear ball bearings or bronze sliding bearings, delivering exceptional resistance to torsion and lateral loads.★Note: Linear ball bearings: Ideal for lifting applications requiring high precision, heavy load capacity, and low-friction movement. Bronze sliding bearings: Specially engineered for radial load applications like braking systems, offering over twice the lateral impact resistance of standard brake cylinders with enhanced torsional rigidity.
3. Integrated design combines driving unit and guiding mechanism within a single body, eliminating additional accessories while providing compact dimensions and adjustable intake ports for flexible installation;
4. Precision positioning holes on base surface, rear end face, and mounting plate (refer to PA holes and XX marked holes in outline drawing) ensure high-accuracy alignment for critical applications;
5. Four sensor grooves on body enable multiple sensor mounting configurations;
6. Proprietary body structure supports multi-orientation mounting solutions;
Category: Adjustable Cylinders | Brand: AIRTAC | Series: TCMJ
AirTAC TCMJ12X40-10S 3-Axis Adjustable Cylinder Specifications
- Model: TCMJ12X40-10S
- Type: 3-axis adjustable pneumatic cylinder (double-acting)
- Bore size: 12mm
- Stroke: 40mm (±20mm adjustable range)
- X/Y/Z-axis adjustment range: ±2mm (each axis)
- Operating pressure: 0.15–0.8 MPa
- Temperature range: -20℃ to 80℃
- Cushioning: Adjustable pneumatic cushion
- Mounting type: Standard base with M5 threaded holes
- Port size: M5x0.8 (Rc1/8 adaptor included)
- Piston rod thread: M6x1.0
- Material: Aluminum alloy body, chrome-plated piston rod
- Seal material: NBR (Nitrile rubber)
- Weight: 0.45kg (including mounting accessories)
- Dimensions: 100mm(L) × 40mm(W) × 40mm(H) (compact position)
- Max lateral load: 3N
- Protection class: IP40
Precision 3-axis micro-adjustable cylinder featuring independent X/Y/Z directional fine-tuning via locking screws. The TCMJ series combines 2mm lateral adjustment capability with 20mm stroke adjustability, enabling sub-millimeter positioning accuracy. Anti-rotation design maintains alignment during multi-axis adjustments. Includes wear-resistant guide bushings and dual dust seals for contaminated environments.
Typical Applications:
- PCB component insertion machines
- Lens positioning in optical assembly
- Precision fixture alignment in CNC tooling
- Semiconductor wafer handling systems
- Automotive sensor calibration jigs
Operation Notes:
- Always depressurize before adjustment
- Use 0.3-0.5 MPa air pressure for initial positioning
- Apply thread locker (LOCTITE 243 recommended) after final alignment
- Max angular misalignment: ±0.5°
Maintenance tip: Clean adjustment threads monthly using compressed air and apply PTFE-based lubricant (e.g., SUPER LUBE 21030) to sliding surfaces every 500,000 cycles.
| Property | Property Value |
|---|---|
| sku | TCMJ12X40-10S |
| Adjustable Stroke | <10mm> |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | M5×0.8 |
| Magnet | S-Magnetic |
| Cushion Type | Bumper Pad |
| Bore Diameter | 12mm |
| Stroke | <40mm> |
