Airtac TCMJ Three-Axis Adjustable Cylinder TCMJ12X50-20S
$85.83
Regular price
$93.33
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
TCMJ12X50-20S
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
1. Complies with JIS standards;
2. Dual guide rods manufactured from specialized bearing steel, guided by linear ball bearings or bronze sliding bearings, delivering exceptional resistance to torsion and lateral loads.★Note: Linear ball bearings: Ideal for lifting applications requiring high precision, heavy load capacity, and low-friction movement. Bronze sliding bearings: Specially engineered for radial load applications like braking systems, offering over twice the lateral impact resistance of standard brake cylinders with enhanced torsional rigidity.
3. Integrated design combines driving unit and guiding mechanism within a single body, eliminating additional accessories while providing compact dimensions and adjustable intake ports for flexible installation;
4. Precision positioning holes on base surface, rear end face, and mounting plate (refer to PA holes and XX marked holes in outline drawing) ensure high-accuracy alignment for critical applications;
5. Four sensor grooves on body enable multiple sensor mounting configurations;
6. Proprietary body structure supports multi-orientation mounting solutions;
Category: Adjustable Cylinders | Brand: AIRTAC | Series: TCMJ
Installation protocol:
Always perform axis alignment before final pneumatic connection. Use 0.5Nm torque limit on adjustment screws.
Requires weekly re-torque checks during first month of operation.
2. Dual guide rods manufactured from specialized bearing steel, guided by linear ball bearings or bronze sliding bearings, delivering exceptional resistance to torsion and lateral loads.★Note: Linear ball bearings: Ideal for lifting applications requiring high precision, heavy load capacity, and low-friction movement. Bronze sliding bearings: Specially engineered for radial load applications like braking systems, offering over twice the lateral impact resistance of standard brake cylinders with enhanced torsional rigidity.
3. Integrated design combines driving unit and guiding mechanism within a single body, eliminating additional accessories while providing compact dimensions and adjustable intake ports for flexible installation;
4. Precision positioning holes on base surface, rear end face, and mounting plate (refer to PA holes and XX marked holes in outline drawing) ensure high-accuracy alignment for critical applications;
5. Four sensor grooves on body enable multiple sensor mounting configurations;
6. Proprietary body structure supports multi-orientation mounting solutions;
Category: Adjustable Cylinders | Brand: AIRTAC | Series: TCMJ
AirTAC TCMJ12X50-20S 3-Axis Adjustable Cylinder Specifications
- Model: TCMJ12X50-20S
- Type: 3-axis adjustable compact cylinder (multi-directional alignment)
- Bore size: 12mm
- Stroke: 50mm (adjustable)
- Operating pressure: 0.15–0.8 MPa
- Temperature range: -20℃ to 80℃
- Cushioning: Adjustable pneumatic cushion (both ends)
- Mounting type: Front flange base with 3-axis slotted holes
- Port size: M5x0.8 (dual ports)
- Rod material: Chrome-plated stainless steel (SUS304)
- Tube material: Anodized aluminum alloy
- Seal material: NBR (nitrile rubber)
- Weight: 0.32kg ±5%
- Dimensions: 107mm(L) × 36mm(W) × 36mm(H) (excluding rod extension)
- Position detection: Pre-installed magnet (PS-12 sensor compatible)
- Protection rating: IP54 (standard seals)
Precision 3-axis alignment cylinder with ±2° angular adjustment capability on all planes. Features integrated locknuts for position retention after alignment. The T-slot design allows 4mm lateral adjustment per axis. Optimized for applications requiring micron-level positioning repeatability in compact spaces.
Typical Applications:
- Semiconductor wafer handling robots
- Precision optical lens assembly systems
- PCB drilling machine Z-axis compensation
- Food packaging gripper alignment
- Medical device testing jigs
Installation protocol:
Always perform axis alignment before final pneumatic connection. Use 0.5Nm torque limit on adjustment screws.
Requires weekly re-torque checks during first month of operation.
Performance Data:
- Maximum lateral load: 3.5N at full extension
- Axial stiffness: 18N/mm
- Cycle life: 5,000km travel distance (clean air)
- Breakaway pressure: ≤0.08 MPa
| Property | Property Value |
|---|---|
| sku | TCMJ12X50-20S |
| Adjustable Stroke | <20mm> |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | M5×0.8 |
| Magnet | S-Magnetic |
| Cushion Type | Bumper Pad |
| Bore Diameter | 12mm |
| Stroke | <50mm> |
