Airtac TCMJ Three-Axis Adjustable Cylinder TCMJ12X70-50S
$88.62
Regular price
$96.12
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
TCMJ12X70-50S
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
1. Complies with JIS standards;
2. Dual guide rods manufactured from specialized bearing steel, guided by linear ball bearings or bronze sliding bearings, delivering exceptional resistance to torsion and lateral loads.★Note: Linear ball bearings: Ideal for lifting applications requiring high precision, heavy load capacity, and low-friction movement. Bronze sliding bearings: Specially engineered for radial load applications like braking systems, offering over twice the lateral impact resistance of standard brake cylinders with enhanced torsional rigidity.
3. Integrated design combines driving unit and guiding mechanism within a single body, eliminating additional accessories while providing compact dimensions and adjustable intake ports for flexible installation;
4. Precision positioning holes on base surface, rear end face, and mounting plate (refer to PA holes and XX marked holes in outline drawing) ensure high-accuracy alignment for critical applications;
5. Four sensor grooves on body enable multiple sensor mounting configurations;
6. Proprietary body structure supports multi-orientation mounting solutions;
Category: Adjustable Cylinders | Brand: AIRTAC | Series: TCMJ
Operation tip:
Use locking nuts (included) after fine-tuning positions. Lubricate guide shafts monthly with ISO VG32 hydraulic oil. Maximum lateral load: 3N·m.
2. Dual guide rods manufactured from specialized bearing steel, guided by linear ball bearings or bronze sliding bearings, delivering exceptional resistance to torsion and lateral loads.★Note: Linear ball bearings: Ideal for lifting applications requiring high precision, heavy load capacity, and low-friction movement. Bronze sliding bearings: Specially engineered for radial load applications like braking systems, offering over twice the lateral impact resistance of standard brake cylinders with enhanced torsional rigidity.
3. Integrated design combines driving unit and guiding mechanism within a single body, eliminating additional accessories while providing compact dimensions and adjustable intake ports for flexible installation;
4. Precision positioning holes on base surface, rear end face, and mounting plate (refer to PA holes and XX marked holes in outline drawing) ensure high-accuracy alignment for critical applications;
5. Four sensor grooves on body enable multiple sensor mounting configurations;
6. Proprietary body structure supports multi-orientation mounting solutions;
Category: Adjustable Cylinders | Brand: AIRTAC | Series: TCMJ
AirTAC TCMJ12X70-50S 3-Axis Adjustable Cylinder Specifications
- Model: TCMJ12X70-50S
- Type: 3-axis adjustable compact cylinder (square body)
- Bore size: Ø12mm
- Stroke: 70mm (adjustable)
- Thread size: M5x0.8 (air ports)
- Operating pressure: 0.05-0.9 MPa
- Ambient temperature: -10℃ to 80℃
- Piston speed: 50-700 mm/s
- Mounting type: 50mm square base (S-type)
- Cushioning: Adjustable rubber bumper
- Material: Aluminum alloy body, CRNA seal
- Weight: 0.48 kg
- Dimensions:
- Body length: 111mm
- Width: 50mm (mounting base)
- Height: 50mm (mounting base)
- Full extended length: 181mm
Precision three-axis adjustable cylinder with unique X/Y/Z alignment capability (±2° angular adjustment). Features dual rod configuration for balanced force distribution and integrated mounting slots for flexible installation. Includes anti-rotation mechanism and dust-resistant wiper seals.
Typical Applications:
- PCB assembly positioning systems
- Laser alignment in semiconductor equipment
- Precision fixture adjustment for CNC tooling
- 3D printing head positioning mechanisms
- Optical lens alignment in inspection machines
Operation tip:
Use locking nuts (included) after fine-tuning positions. Lubricate guide shafts monthly with ISO VG32 hydraulic oil. Maximum lateral load: 3N·m.
Adjustment Procedure:
- Loosen four axis-lock screws with 2mm hex key
- Adjust X/Y/Z positions using calibration marks
- Re-tighten screws in cross pattern (0.7-1.0N·m torque)
- Verify alignment with test cycle
| Property | Property Value |
|---|---|
| sku | TCMJ12X70-50S |
| Adjustable Stroke | <50mm> |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | M5×0.8 |
| Magnet | S-Magnetic |
| Cushion Type | Bumper Pad |
| Bore Diameter | 12mm |
| Stroke | 70mm |
