Airtac TCMJ Three-Axis Adjustable Cylinder TCMJ12X75-10S
$89.29
Regular price
$96.79
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
TCMJ12X75-10S
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
1. Complies with JIS standards;
2. Dual guide rods manufactured from specialized bearing steel, guided by linear ball bearings or bronze sliding bearings, delivering exceptional resistance to torsion and lateral loads.★Note: Linear ball bearings: Ideal for lifting applications requiring high precision, heavy load capacity, and low-friction movement. Bronze sliding bearings: Specially engineered for radial load applications like braking systems, offering over twice the lateral impact resistance of standard brake cylinders with enhanced torsional rigidity.
3. Integrated design combines driving unit and guiding mechanism within a single body, eliminating additional accessories while providing compact dimensions and adjustable intake ports for flexible installation;
4. Precision positioning holes on base surface, rear end face, and mounting plate (refer to PA holes and XX marked holes in outline drawing) ensure high-accuracy alignment for critical applications;
5. Four sensor grooves on body enable multiple sensor mounting configurations;
6. Proprietary body structure supports multi-orientation mounting solutions;
Category: Adjustable Cylinders | Brand: AIRTAC | Series: TCMJ
Installation tip:
Always perform axis alignment verification after installation using dial indicators.
Recommended maintenance cycle: Relubricate every 500,000 cycles or 6 months.
2. Dual guide rods manufactured from specialized bearing steel, guided by linear ball bearings or bronze sliding bearings, delivering exceptional resistance to torsion and lateral loads.★Note: Linear ball bearings: Ideal for lifting applications requiring high precision, heavy load capacity, and low-friction movement. Bronze sliding bearings: Specially engineered for radial load applications like braking systems, offering over twice the lateral impact resistance of standard brake cylinders with enhanced torsional rigidity.
3. Integrated design combines driving unit and guiding mechanism within a single body, eliminating additional accessories while providing compact dimensions and adjustable intake ports for flexible installation;
4. Precision positioning holes on base surface, rear end face, and mounting plate (refer to PA holes and XX marked holes in outline drawing) ensure high-accuracy alignment for critical applications;
5. Four sensor grooves on body enable multiple sensor mounting configurations;
6. Proprietary body structure supports multi-orientation mounting solutions;
Category: Adjustable Cylinders | Brand: AIRTAC | Series: TCMJ
AirTAC TCMJ Series 3-Axis Adjustable Cylinder TCMJ12X75-10S Specifications
- Model: TCMJ12X75-10S
- Type: 3-axis adjustable compact cylinder (X/Y/Z adjustable)
- Bore size: 12mm
- Stroke: 75mm (±1.5mm adjustable range)
- Operating pressure: 0.15–0.8 MPa
- Operation direction: Double-acting
- Adjustment method: Hex socket set screw locking
- Mounting style: Double-pivot bracket (standard)
- Weight: 0.45kg (excluding accessories)
- Dimensions: 125mm(L) × 38mm(W) × 38mm(H) (at neutral position)
- Temperature range: -10℃ to 70℃
- Buffer type: Rubber cushion (both ends)
- Material: Aluminum alloy body, NBR seals
- Port size: M5x0.8 (dual ports)
- Protection rating: IP40 (standard)
- Rod thread: M6x1.0 (male thread at both ends)
Precision multi-axis positioning cylinder featuring micrometer-style fine adjustment (±1.5mm) on all three axes. The TCMJ series incorporates a unique double-lock mechanism with hex socket screws for vibration-resistant position retention. Optimized for applications requiring sub-millimeter alignment accuracy in confined spaces. Requires filtered air (5-50μm) with ISO VG32 lubricator oil mist.
Typical Applications:
- PCB handling robot end-effector positioning
- Semiconductor wafer alignment mechanisms
- Precision fixture micro-adjustment systems
- Optical lens assembly equipment
- 3D printer nozzle calibration devices
Installation tip:
Always perform axis alignment verification after installation using dial indicators.
Recommended maintenance cycle: Relubricate every 500,000 cycles or 6 months.
Note: Maximum lateral load capacity 15N. For angular adjustments beyond ±3°,
use supplemental support brackets. Avoid using impact tools for hex screw adjustments.
| Property | Property Value |
|---|---|
| sku | TCMJ12X75-10S |
| Adjustable Stroke | <10mm> |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | M5×0.8 |
| Magnet | S-Magnetic |
| Cushion Type | Bumper Pad |
| Bore Diameter | 12mm |
| Stroke | 75mm |
