Airtac TCMJ Three-Axis Adjustable Cylinder TCMJ12X90-30S
$91.41
Regular price
$98.91
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
TCMJ12X90-30S
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
1. Complies with JIS standards;
2. Dual guide rods manufactured from specialized bearing steel, guided by linear ball bearings or bronze sliding bearings, delivering exceptional resistance to torsion and lateral loads.★Note: Linear ball bearings: Ideal for lifting applications requiring high precision, heavy load capacity, and low-friction movement. Bronze sliding bearings: Specially engineered for radial load applications like braking systems, offering over twice the lateral impact resistance of standard brake cylinders with enhanced torsional rigidity.
3. Integrated design combines driving unit and guiding mechanism within a single body, eliminating additional accessories while providing compact dimensions and adjustable intake ports for flexible installation;
4. Precision positioning holes on base surface, rear end face, and mounting plate (refer to PA holes and XX marked holes in outline drawing) ensure high-accuracy alignment for critical applications;
5. Four sensor grooves on body enable multiple sensor mounting configurations;
6. Proprietary body structure supports multi-orientation mounting solutions;
Category: Adjustable Cylinders | Brand: AIRTAC | Series: TCMJ
Installation protocol:
Always perform axis alignment using dial indicators during mounting.
Lubricate with ISO VG32 hydraulic oil before initial operation.
Avoid side loads exceeding 15N to maintain adjustment accuracy.
2. Dual guide rods manufactured from specialized bearing steel, guided by linear ball bearings or bronze sliding bearings, delivering exceptional resistance to torsion and lateral loads.★Note: Linear ball bearings: Ideal for lifting applications requiring high precision, heavy load capacity, and low-friction movement. Bronze sliding bearings: Specially engineered for radial load applications like braking systems, offering over twice the lateral impact resistance of standard brake cylinders with enhanced torsional rigidity.
3. Integrated design combines driving unit and guiding mechanism within a single body, eliminating additional accessories while providing compact dimensions and adjustable intake ports for flexible installation;
4. Precision positioning holes on base surface, rear end face, and mounting plate (refer to PA holes and XX marked holes in outline drawing) ensure high-accuracy alignment for critical applications;
5. Four sensor grooves on body enable multiple sensor mounting configurations;
6. Proprietary body structure supports multi-orientation mounting solutions;
Category: Adjustable Cylinders | Brand: AIRTAC | Series: TCMJ
AirTAC TCMJ12X90-30S 3-Axis Adjustable Cylinder Technical Details
- Model Code: TCMJ12X90-30S
- Bore Size: Ø12mm (Precision ground cylinder)
- Stroke: 90mm ±0.5mm (Effective travel)
- Adjustment Range: ±3mm (X/Y/Z axes via micrometer screws)
- Operating Pressure: 0.1–0.9 MPa (14–130 PSI)
- Temperature Range: -10℃ to 80℃ (Dry air required below 0℃)
- Port Size: M5x0.8 (Dual Rc1/8 ports optional)
- Mounting Type: Dual through-holes with M4x0.7 threads
- Rod Material: Chrome-plated SUS304 stainless steel
- Tube Material: Anodized aluminum alloy 6063-T5
- Cushioning: Adjustable rubber buffers (both ends)
- Repeat Positioning Accuracy: ±0.02mm
- Protection Class: IP54 (Dust-resistant with water spray protection)
- Weight: 850g ±3% (Without accessories)
- Dimensions: 178mm(L) × 52mm(W) × 48mm(H) (Fully retracted)
High-precision 3-axis alignment cylinder featuring micron-level adjustment capability through integrated differential screws (0.01mm/division). The TCMJ series incorporates anti-rotation guidance rails and wear-resistant PTFE seals for stable repeat positioning. Includes dual auto-exhaust valves and optional magnetic sensor slots (M9 connector compatible). Requires ISO 8573-1:2010 Class 3 compressed air.
Industrial Applications:
- PCB component insertion machines (Z-axis final alignment)
- Lens polishing equipment requiring micron adjustments
- Robotic end-effector calibration stations
- Semiconductor wafer handling systems
- Optical measurement device positioning stages
Installation protocol:
Always perform axis alignment using dial indicators during mounting.
Lubricate with ISO VG32 hydraulic oil before initial operation.
Avoid side loads exceeding 15N to maintain adjustment accuracy.
Accessory Pairing:
- Use ASL10-02A adjustable stoppers for multi-position setups
- Pair with SNS-LS08 magnetic sensors for position feedback
- Recommended regulator: AR2000-02BG with 5μm filter
| Property | Property Value |
|---|---|
| sku | TCMJ12X90-30S |
| Adjustable Stroke | 30mm |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | M5×0.8 |
| Magnet | S-Magnetic |
| Cushion Type | Bumper Pad |
| Bore Diameter | 12mm |
| Stroke | 90mm |
