Airtac TCMJ Three-Axis Adjustable Cylinder TCMJ16X10-10S
$84.44
Regular price
$91.94
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
TCMJ16X10-10S
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
1. Complies with JIS standards;
2. Dual guide rods manufactured from specialized bearing steel, guided by linear ball bearings or bronze sliding bearings, delivering exceptional resistance to torsion and lateral loads.★Note: Linear ball bearings: Ideal for lifting applications requiring high precision, heavy load capacity, and low-friction movement. Bronze sliding bearings: Specially engineered for radial load applications like braking systems, offering over twice the lateral impact resistance of standard brake cylinders with enhanced torsional rigidity.
3. Integrated design combines driving unit and guiding mechanism within a single body, eliminating additional accessories while providing compact dimensions and adjustable intake ports for flexible installation;
4. Precision positioning holes on base surface, rear end face, and mounting plate (refer to PA holes and XX marked holes in outline drawing) ensure high-accuracy alignment for critical applications;
5. Four sensor grooves on body enable multiple sensor mounting configurations;
6. Proprietary body structure supports multi-orientation mounting solutions;
Category: Adjustable Cylinders | Brand: AIRTAC | Series: TCMJ
Installation tip:
Use M3×8mm mounting screws (max torque 0.6N·m). For thermal stability,
allow 15-minute warm-up period in temperature-controlled environments.
Apply silicone grease (JIS K2220) to adjustment screws quarterly.
2. Dual guide rods manufactured from specialized bearing steel, guided by linear ball bearings or bronze sliding bearings, delivering exceptional resistance to torsion and lateral loads.★Note: Linear ball bearings: Ideal for lifting applications requiring high precision, heavy load capacity, and low-friction movement. Bronze sliding bearings: Specially engineered for radial load applications like braking systems, offering over twice the lateral impact resistance of standard brake cylinders with enhanced torsional rigidity.
3. Integrated design combines driving unit and guiding mechanism within a single body, eliminating additional accessories while providing compact dimensions and adjustable intake ports for flexible installation;
4. Precision positioning holes on base surface, rear end face, and mounting plate (refer to PA holes and XX marked holes in outline drawing) ensure high-accuracy alignment for critical applications;
5. Four sensor grooves on body enable multiple sensor mounting configurations;
6. Proprietary body structure supports multi-orientation mounting solutions;
Category: Adjustable Cylinders | Brand: AIRTAC | Series: TCMJ
AirTAC TCMJ16X10-10S 3-Axis Adjustable Cylinder Specifications
- Model: TCMJ16X10-10S
- Type: 3-axis adjustable compact cylinder (rodless type)
- Bore size: 16mm
- Stroke: 10mm
- Adjustment range: ±2mm (X/Y/Z axes)
- Operating pressure: 0.05-0.9 MPa
- Temperature range: -10℃ to 70℃
- Mounting style: Dual foot + front flange
- Body material: Anodized aluminum alloy
- Piston material: Stainless steel SUS304
- Seal type: NBR rubber with wear-resistant ring
- Cushioning: Adjustable rubber bumper
- Weight: 0.42kg (excluding accessories)
- Dimensions: 66mm(W) × 25mm(H) × 55mm(L)
- Protection class: IP54 (standard), IP67 optional
- Lubrication: Pre-lubricated (DOP mist lubrication compatible)
Precision multi-axis positioning cylinder featuring micrometer-style fine adjustment screws (0.1mm/division) on all three axes. Integrated T-slot design allows direct mounting of sensors or tooling plates. Optimized for vibration resistance with dual guide rods and chromium-plated shafts. Includes anti-rotation mechanism for stable vertical operation.
Typical Applications:
- Semiconductor wafer handling robots
- Precision die-cutting machine alignment systems
- Lens polishing equipment position adjustment
- Automated optical inspection (AOI) stages
- PCB drilling machine Z-axis compensation
Installation tip:
Use M3×8mm mounting screws (max torque 0.6N·m). For thermal stability,
allow 15-minute warm-up period in temperature-controlled environments.
Apply silicone grease (JIS K2220) to adjustment screws quarterly.
| Property | Property Value |
|---|---|
| sku | TCMJ16X10-10S |
| Adjustable Stroke | <10mm> |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | M5×0.8 |
| Magnet | S-Magnetic |
| Cushion Type | Bumper Pad |
| Bore Diameter | 16mm |
| Stroke | <10mm> |
