Airtac TCMJ Three-Axis Adjustable Cylinder TCMJ16X125-10S
$104.18
Regular price
$111.68
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
TCMJ16X125-10S
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
1. Complies with JIS standards;
2. Dual guide rods manufactured from specialized bearing steel, guided by linear ball bearings or bronze sliding bearings, delivering exceptional resistance to torsion and lateral loads.★Note: Linear ball bearings: Ideal for lifting applications requiring high precision, heavy load capacity, and low-friction movement. Bronze sliding bearings: Specially engineered for radial load applications like braking systems, offering over twice the lateral impact resistance of standard brake cylinders with enhanced torsional rigidity.
3. Integrated design combines driving unit and guiding mechanism within a single body, eliminating additional accessories while providing compact dimensions and adjustable intake ports for flexible installation;
4. Precision positioning holes on base surface, rear end face, and mounting plate (refer to PA holes and XX marked holes in outline drawing) ensure high-accuracy alignment for critical applications;
5. Four sensor grooves on body enable multiple sensor mounting configurations;
6. Proprietary body structure supports multi-orientation mounting solutions;
Category: Adjustable Cylinders | Brand: AIRTAC | Series: TCMJ
Installation note:
Always lock adjustment screws with 0.3–0.5 N·m torque after alignment.
Use in vertical orientation requires additional lateral support bracket (sold separately).
2. Dual guide rods manufactured from specialized bearing steel, guided by linear ball bearings or bronze sliding bearings, delivering exceptional resistance to torsion and lateral loads.★Note: Linear ball bearings: Ideal for lifting applications requiring high precision, heavy load capacity, and low-friction movement. Bronze sliding bearings: Specially engineered for radial load applications like braking systems, offering over twice the lateral impact resistance of standard brake cylinders with enhanced torsional rigidity.
3. Integrated design combines driving unit and guiding mechanism within a single body, eliminating additional accessories while providing compact dimensions and adjustable intake ports for flexible installation;
4. Precision positioning holes on base surface, rear end face, and mounting plate (refer to PA holes and XX marked holes in outline drawing) ensure high-accuracy alignment for critical applications;
5. Four sensor grooves on body enable multiple sensor mounting configurations;
6. Proprietary body structure supports multi-orientation mounting solutions;
Category: Adjustable Cylinders | Brand: AIRTAC | Series: TCMJ
AirTAC TCMJ16X125-10S 3-Axis Adjustable Cylinder Specifications
- Model: TCMJ16X125-10S
- Type: 3-axis adjustable double-acting pneumatic cylinder
- Bore size: 16mm (0.63")
- Stroke: 125mm (4.92")
- Adjustment range: ±2mm on X/Y axes, ±5° angular adjustment on Z-axis
- Operating pressure: 0.15–0.8 MPa (21.7–116 PSI)
- Mounting style: Through-hole base mount with M5x0.8 threaded holes
- Cushioning: Adjustable pneumatic cushion at both ends
- Piston rod material: Hard chrome-plated steel
- Tube material: Anodized aluminum alloy
- Seal material: NBR (Nitrile rubber)
- Temperature range: -20℃ to 80℃ (-4°F to 176°F)
- Port size: M5x0.8 (1/8" NPT adapter optional)
- Weight: 1.45 kg (3.2 lbs)
- Dimensions (L×W×H):
- Extended length: 258mm (10.16")
- Retracted length: 133mm (5.24")
- Main body width: 40mm (1.57")
- Adjustment block height: 32mm (1.26")
- Protection rating: IP54 (standard wiper seal)
A precision alignment cylinder with micrometer-style adjustment screws (0.1mm/division) for three-dimensional positioning. Features anti-rotation mechanism and wear-resistant guide bushings. Requires filtered air (40μm) with ISO VG32-grade lubricant.
Typical Applications:
- Automated jig positioning systems
- PCB assembly machine component alignment
- Robotic end-effector fine adjustment
- Optical lens manufacturing fixtures
- Precision stamping press tool guides
Installation note:
Always lock adjustment screws with 0.3–0.5 N·m torque after alignment.
Use in vertical orientation requires additional lateral support bracket (sold separately).
| Property | Property Value |
|---|---|
| sku | TCMJ16X125-10S |
| Adjustable Stroke | <10mm> |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | M5×0.8 |
| Magnet | S-Magnetic |
| Cushion Type | Bumper Pad |
| Bore Diameter | 16mm |
| Stroke | 125mm |
