Airtac TCMJ Three-Axis Adjustable Cylinder TCMJ16X175-50S
$113.03
Regular price
$120.53
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
TCMJ16X175-50S
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
1. Complies with JIS standards;
2. Dual guide rods manufactured from specialized bearing steel, guided by linear ball bearings or bronze sliding bearings, delivering exceptional resistance to torsion and lateral loads.★Note: Linear ball bearings: Ideal for lifting applications requiring high precision, heavy load capacity, and low-friction movement. Bronze sliding bearings: Specially engineered for radial load applications like braking systems, offering over twice the lateral impact resistance of standard brake cylinders with enhanced torsional rigidity.
3. Integrated design combines driving unit and guiding mechanism within a single body, eliminating additional accessories while providing compact dimensions and adjustable intake ports for flexible installation;
4. Precision positioning holes on base surface, rear end face, and mounting plate (refer to PA holes and XX marked holes in outline drawing) ensure high-accuracy alignment for critical applications;
5. Four sensor grooves on body enable multiple sensor mounting configurations;
6. Proprietary body structure supports multi-orientation mounting solutions;
Category: Adjustable Cylinders | Brand: AIRTAC | Series: TCMJ
Installation note:
Always perform axis synchronization calibration using included alignment jigs.
Maintain 0.5mm minimum clearance between adjustment screws during operation.
Lubricate with ISO VG32 hydraulic oil monthly in high-cycle applications (>500k cycles/yr).
2. Dual guide rods manufactured from specialized bearing steel, guided by linear ball bearings or bronze sliding bearings, delivering exceptional resistance to torsion and lateral loads.★Note: Linear ball bearings: Ideal for lifting applications requiring high precision, heavy load capacity, and low-friction movement. Bronze sliding bearings: Specially engineered for radial load applications like braking systems, offering over twice the lateral impact resistance of standard brake cylinders with enhanced torsional rigidity.
3. Integrated design combines driving unit and guiding mechanism within a single body, eliminating additional accessories while providing compact dimensions and adjustable intake ports for flexible installation;
4. Precision positioning holes on base surface, rear end face, and mounting plate (refer to PA holes and XX marked holes in outline drawing) ensure high-accuracy alignment for critical applications;
5. Four sensor grooves on body enable multiple sensor mounting configurations;
6. Proprietary body structure supports multi-orientation mounting solutions;
Category: Adjustable Cylinders | Brand: AIRTAC | Series: TCMJ
AirTAC TCMJ16X175-50S 3-Axis Adjustable Cylinder Specifications
- Model: TCMJ16X175-50S
- Type: Triple-axis adjustable cylinder with male rod threads
- Bore size: 16mm
- Stroke: 175mm (±1mm tolerance)
- Operating pressure: 0.1–0.9 MPa
- Piston speed: 50–800 mm/s (lubricated)
- Temperature range: -20℃ to 80℃
- Port size: M5x0.8 (dual ports per axis)
- Adjustment range: ±2° angular compensation (X/Y/Z axes)
- Mounting style: Front flange with 4xM4 threaded holes
- Rod end: M6x1 external thread (8mm projection)
- Cushioning: Adjustable air cushion (3-stage)
- Material: Aluminum alloy body, chrome-plated piston rod
- Seals: NBR + PU combination
- Weight: 820g ±2%
- Dimensions: 305mm(L) × 52mm(W) × 52mm(H) (fully retracted)
Precision triple-axis compensator cylinder with micron-level alignment capability (≤±0.05mm repeatability). Features anti-rotation guidance system and torque-resistant structure for multi-directional force applications. Includes built-in shock absorbers and dust-resistant wiper seals. Requires ISO 8573-1:2010 [4:4:3] class compressed air.
Typical Applications:
- PCB component insertion machines (Z-axis compensation)
- Robotic end-effector alignment systems
- Optical lens assembly positioning stages
- Automated welding gun nozzle alignment
- Semiconductor wafer handling robots
Installation note:
Always perform axis synchronization calibration using included alignment jigs.
Maintain 0.5mm minimum clearance between adjustment screws during operation.
Lubricate with ISO VG32 hydraulic oil monthly in high-cycle applications (>500k cycles/yr).
| Property | Property Value |
|---|---|
| sku | TCMJ16X175-50S |
| Adjustable Stroke | <50mm> |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | M5×0.8 |
| Magnet | S-Magnetic |
| Cushion Type | Bumper Pad |
| Bore Diameter | 16mm |
| Stroke | 175mm |
