Airtac TCMJ Three-Axis Adjustable Cylinder TCMJ16X20-10S
$85.36
Regular price
$92.86
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
TCMJ16X20-10S
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
1. Complies with JIS standards;
2. Dual guide rods manufactured from specialized bearing steel, guided by linear ball bearings or bronze sliding bearings, delivering exceptional resistance to torsion and lateral loads.★Note: Linear ball bearings: Ideal for lifting applications requiring high precision, heavy load capacity, and low-friction movement. Bronze sliding bearings: Specially engineered for radial load applications like braking systems, offering over twice the lateral impact resistance of standard brake cylinders with enhanced torsional rigidity.
3. Integrated design combines driving unit and guiding mechanism within a single body, eliminating additional accessories while providing compact dimensions and adjustable intake ports for flexible installation;
4. Precision positioning holes on base surface, rear end face, and mounting plate (refer to PA holes and XX marked holes in outline drawing) ensure high-accuracy alignment for critical applications;
5. Four sensor grooves on body enable multiple sensor mounting configurations;
6. Proprietary body structure supports multi-orientation mounting solutions;
Category: Adjustable Cylinders | Brand: AIRTAC | Series: TCMJ
Installation protocol:
Always perform axis alignment before locking screws - use 0.3Nm torque for adjustment bolts and 1.2Nm for final locking. Maintain 0.5mm minimum clearance between cylinder body and adjacent components to prevent thermal expansion interference.
2. Dual guide rods manufactured from specialized bearing steel, guided by linear ball bearings or bronze sliding bearings, delivering exceptional resistance to torsion and lateral loads.★Note: Linear ball bearings: Ideal for lifting applications requiring high precision, heavy load capacity, and low-friction movement. Bronze sliding bearings: Specially engineered for radial load applications like braking systems, offering over twice the lateral impact resistance of standard brake cylinders with enhanced torsional rigidity.
3. Integrated design combines driving unit and guiding mechanism within a single body, eliminating additional accessories while providing compact dimensions and adjustable intake ports for flexible installation;
4. Precision positioning holes on base surface, rear end face, and mounting plate (refer to PA holes and XX marked holes in outline drawing) ensure high-accuracy alignment for critical applications;
5. Four sensor grooves on body enable multiple sensor mounting configurations;
6. Proprietary body structure supports multi-orientation mounting solutions;
Category: Adjustable Cylinders | Brand: AIRTAC | Series: TCMJ
AirTAC TCMJ16X20-10S 3-Axis Adjustable Cylinder Specifications
- Model: TCMJ16X20-10S
- Type: Triple-axis adjustable compact cylinder (rodless type)
- Bore size: 16mm
- Stroke: 20mm ±1mm adjustable
- Axis adjustment range: X/Y/Z axes ±2° angular adjustment
- Mounting type: Standard side-mount with M4 threaded holes
- Operating pressure: 0.05-0.9 MPa
- Max speed: 500mm/s
- Cushioning: Elastic rubber buffer + adjustable air cushion
- Repeat positioning accuracy: ±0.1mm
- Material: Aluminum alloy barrel (hard anodized), CRCA piston rod
- Temperature range: -10℃ to 80℃
- Port size: M5x0.8 (dual ports)
- Weight: 280g ±5g
- Dimensions: 98mm(L) × 34mm(W) × 34mm(H) (minimum contracted length)
- Accessories: Includes mounting bracket set (PJ16) and 2x hex key wrenches
Precision triple-axis alignment cylinder with micron-level adjustment capability, featuring integrated locking screws for positional stability after calibration. The corrosion-resistant design incorporates dual sealing layers (NBR + PTFE) for leak-proof operation in humid environments. Requires filtered air (5-40μm) with ISO VG32-grade lubrication.
Typical Applications:
- PCB component insertion machines (Z-axis final alignment)
- Robotic end-effector position fine-tuning
- Optical lens assembly positioning systems
- Semiconductor wafer handling equipment
- 3D printer nozzle calibration mechanisms
Installation protocol:
Always perform axis alignment before locking screws - use 0.3Nm torque for adjustment bolts and 1.2Nm for final locking. Maintain 0.5mm minimum clearance between cylinder body and adjacent components to prevent thermal expansion interference.
| Property | Property Value |
|---|---|
| sku | TCMJ16X20-10S |
| Adjustable Stroke | <10mm> |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | M5×0.8 |
| Magnet | S-Magnetic |
| Cushion Type | Bumper Pad |
| Bore Diameter | 16mm |
| Stroke | <20mm> |
