Airtac TCMJ Three-Axis Adjustable Cylinder TCMJ16X50-20S
2. Dual guide rods manufactured from specialized bearing steel, guided by linear ball bearings or bronze sliding bearings, delivering exceptional resistance to torsion and lateral loads.★Note: Linear ball bearings: Ideal for lifting applications requiring high precision, heavy load capacity, and low-friction movement. Bronze sliding bearings: Specially engineered for radial load applications like braking systems, offering over twice the lateral impact resistance of standard brake cylinders with enhanced torsional rigidity.
3. Integrated design combines driving unit and guiding mechanism within a single body, eliminating additional accessories while providing compact dimensions and adjustable intake ports for flexible installation;
4. Precision positioning holes on base surface, rear end face, and mounting plate (refer to PA holes and XX marked holes in outline drawing) ensure high-accuracy alignment for critical applications;
5. Four sensor grooves on body enable multiple sensor mounting configurations;
6. Proprietary body structure supports multi-orientation mounting solutions;
Category: Adjustable Cylinders | Brand: AIRTAC | Series: TCMJ
AirTAC TCMJ16X50-20S 3-Axis Adjustable Cylinder Technical Details
- Model Code: TCMJ16X50-20S
- Type: 3-axis adjustable compact cylinder (rodless type)
- Bore size: 16mm
- Stroke: 50mm ±0.5mm (adjustable via stopper)
- Operating pressure: 0.05-0.9 MPa
- Max thrust: 180N @0.5MPa
- Ambient temperature: -20℃ to 80℃
- Port size: M5×0.8 (dual ports per axis)
- Body material: Anodized aluminum alloy (AL6063-T5)
- Seal material: Heat-resistant NBR (-10℃ to 100℃)
- Position detection: Optional magnetic switch (2-wire/3-wire)
- Mounting: Dual-axis horizontal/vertical via M4 threaded holes
- Weight: 0.68kg (excluding accessories)
- Dimensions: 130mm(L) × 42mm(W) × 52mm(H)
- Repeat accuracy: ±0.1mm
- Cushioning: Adjustable rubber buffers (X/Y/Z axes)
Modular multi-axis pneumatic actuator featuring micron-level positioning through mechanical stoppers. The TCMJ series combines three independent cylinders in orthogonal configuration with 360° adjustable mounting surfaces. Integrated T-slot design enables tooling plate attachment without additional brackets. Optimized for multi-directional force applications requiring synchronized linear movements.
- Semiconductor wafer handling robots (XYZ alignment)
- Precision fixture positioning in CNC machining centers
- 3D inspection probe manipulators
- Automated optical calibration systems
- Packaging machine product orientation adjusters
Installation protocol:
Lubricate all axes with ISO VG32 turbine oil before initial operation.
Align master axis first (marked with red indicator) during assembly.
Maintain 0.5mm minimum clearance between stopper screws.
| Property | Property Value |
|---|---|
| sku | TCMJ16X50-20S |
| Adjustable Stroke | <20mm> |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | M5×0.8 |
| Magnet | S-Magnetic |
| Cushion Type | Bumper Pad |
| Bore Diameter | 16mm |
| Stroke | <50mm> |
