Airtac TCMJ Three-Axis Adjustable Cylinder TCMJ16X60-30S
$93.95
Regular price
$101.45
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
TCMJ16X60-30S
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
1. Complies with JIS standards;
2. Dual guide rods manufactured from specialized bearing steel, guided by linear ball bearings or bronze sliding bearings, delivering exceptional resistance to torsion and lateral loads.★Note: Linear ball bearings: Ideal for lifting applications requiring high precision, heavy load capacity, and low-friction movement. Bronze sliding bearings: Specially engineered for radial load applications like braking systems, offering over twice the lateral impact resistance of standard brake cylinders with enhanced torsional rigidity.
3. Integrated design combines driving unit and guiding mechanism within a single body, eliminating additional accessories while providing compact dimensions and adjustable intake ports for flexible installation;
4. Precision positioning holes on base surface, rear end face, and mounting plate (refer to PA holes and XX marked holes in outline drawing) ensure high-accuracy alignment for critical applications;
5. Four sensor grooves on body enable multiple sensor mounting configurations;
6. Proprietary body structure supports multi-orientation mounting solutions;
Category: Adjustable Cylinders | Brand: AIRTAC | Series: TCMJ
Installation note:
Always lock adjustment screws in sequence (X-axis → Y-axis → Z-axis) using 0.3Nm torque.
Maintain 0.5mm minimum clearance between adjacent moving parts. Lubricate guide rails monthly with #2 lithium grease.
2. Dual guide rods manufactured from specialized bearing steel, guided by linear ball bearings or bronze sliding bearings, delivering exceptional resistance to torsion and lateral loads.★Note: Linear ball bearings: Ideal for lifting applications requiring high precision, heavy load capacity, and low-friction movement. Bronze sliding bearings: Specially engineered for radial load applications like braking systems, offering over twice the lateral impact resistance of standard brake cylinders with enhanced torsional rigidity.
3. Integrated design combines driving unit and guiding mechanism within a single body, eliminating additional accessories while providing compact dimensions and adjustable intake ports for flexible installation;
4. Precision positioning holes on base surface, rear end face, and mounting plate (refer to PA holes and XX marked holes in outline drawing) ensure high-accuracy alignment for critical applications;
5. Four sensor grooves on body enable multiple sensor mounting configurations;
6. Proprietary body structure supports multi-orientation mounting solutions;
Category: Adjustable Cylinders | Brand: AIRTAC | Series: TCMJ
AirTAC TCMJ16X60-30S Three-Axis Adjustable Cylinder Specifications
- Model: TCMJ16X60-30S
- Type: Three-axis adjustable cylinder (mechanical lock type)
- Bore size: 16mm
- Stroke: 60mm (±3mm adjustable via lock nuts)
- Rod diameter: 6mm
- Operating pressure: 0.1–0.9 MPa
- Ambient temperature: -20℃ to 80℃
- Piston speed: 50–800 mm/s
- Mounting style: Dual horizontal axis adjustment + vertical stroke
- Adjustment range: X/Y axes ±3°, Z axis ±2mm
- Port size: M5x0.8 (Rc1/8 adaptor optional)
- Cushioning: Adjustable rubber buffer
- Material: Aluminum alloy body, chrome-plated piston rod
- Seal type: NBR seals (FKM available for high-temp)
- Weight: 820g ±3% (without accessories)
- Dimensions: 120mm(L) × 45mm(W) × 45mm(H) (max extended position)
Precision three-dimensional positioning cylinder with mechanical locking mechanism for micron-level adjustments. Features dual-axis angular compensation (±3°) and vertical stroke fine-tuning (±2mm) through calibrated lock nuts. Anodized surface treatment resists industrial contaminants. Requires 5μm filtered air with ISO VG32 lubricant.
Typical Applications:
- PCB assembly positioning systems
- Semiconductor wafer handling robots
- Precision fixture alignment in CNC machining
- 3D inspection equipment calibration
- Medical device assembly automation
Installation note:
Always lock adjustment screws in sequence (X-axis → Y-axis → Z-axis) using 0.3Nm torque.
Maintain 0.5mm minimum clearance between adjacent moving parts. Lubricate guide rails monthly with #2 lithium grease.
| Property | Property Value |
|---|---|
| sku | TCMJ16X60-30S |
| Adjustable Stroke | 30mm |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | M5×0.8 |
| Magnet | S-Magnetic |
| Cushion Type | Bumper Pad |
| Bore Diameter | 16mm |
| Stroke | 60mm |
