Airtac TCMJ Three-Axis Adjustable Cylinder TCMJ20X175-100S
$140.94
Regular price
$148.44
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
TCMJ20X175-100S
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
1. Complies with JIS standards;
2. Dual guide rods manufactured from specialized bearing steel, guided by linear ball bearings or bronze sliding bearings, delivering exceptional resistance to torsion and lateral loads.★Note: Linear ball bearings: Ideal for lifting applications requiring high precision, heavy load capacity, and low-friction movement. Bronze sliding bearings: Specially engineered for radial load applications like braking systems, offering over twice the lateral impact resistance of standard brake cylinders with enhanced torsional rigidity.
3. Integrated design combines driving unit and guiding mechanism within a single body, eliminating additional accessories while providing compact dimensions and adjustable intake ports for flexible installation;
4. Precision positioning holes on base surface, rear end face, and mounting plate (refer to PA holes and XX marked holes in outline drawing) ensure high-accuracy alignment for critical applications;
5. Four sensor grooves on body enable multiple sensor mounting configurations;
6. Proprietary body structure supports multi-orientation mounting solutions;
Category: Adjustable Cylinders | Brand: AIRTAC | Series: TCMJ
Installation note:
Requires periodic lubrication (ISO VG32 hydraulic oil recommended).
Avoid side-load forces exceeding 30N. Locking screws should be torqued
to 1.2N·m±10% after final position adjustment.
2. Dual guide rods manufactured from specialized bearing steel, guided by linear ball bearings or bronze sliding bearings, delivering exceptional resistance to torsion and lateral loads.★Note: Linear ball bearings: Ideal for lifting applications requiring high precision, heavy load capacity, and low-friction movement. Bronze sliding bearings: Specially engineered for radial load applications like braking systems, offering over twice the lateral impact resistance of standard brake cylinders with enhanced torsional rigidity.
3. Integrated design combines driving unit and guiding mechanism within a single body, eliminating additional accessories while providing compact dimensions and adjustable intake ports for flexible installation;
4. Precision positioning holes on base surface, rear end face, and mounting plate (refer to PA holes and XX marked holes in outline drawing) ensure high-accuracy alignment for critical applications;
5. Four sensor grooves on body enable multiple sensor mounting configurations;
6. Proprietary body structure supports multi-orientation mounting solutions;
Category: Adjustable Cylinders | Brand: AIRTAC | Series: TCMJ
AirTAC TCMJ20X175-100S 3-Axis Adjustable Cylinder Specifications
- Model: TCMJ20X175-100S
- Type: Triple-axis adjustable cylinder (rodless type)
- Bore size: 20mm
- Stroke: 175mm (max travel)
- Adjustment range: ±50mm on X/Y/Z axes
- Operating pressure: 0.1-0.9 MPa
- Operating temperature: -10℃ to 70℃
- Cushioning: Adjustable rubber buffers
- Port size: M5x0.8 (standard) / NPT1/8 (optional)
- Material: Aluminum alloy body, CRMO steel guide rods
- Seal type: NBR seals with wear-resistant rings
- Weight: 2.8kg (with all accessories)
- Dimensions: 280mm(L) × 62mm(W) × 62mm(H) (retracted position)
- Mounting: Dual M6 threaded holes on base
- Protection rating: IP54 (standard) / IP67 (optional)
Precision multi-axis positioning cylinder with micrometer-grade adjustment capability (±0.05mm repeatability). Features anti-rotation mechanism and integrated shock absorption. Designed for applications requiring micron-level positional accuracy across three planes. Includes mounting jigs for simplified alignment.
Typical Applications:
- Semiconductor wafer handling robots
- Optical lens alignment systems
- PCB drilling machine positioning
- Automated inspection equipment calibration
- Precision mold adjustment mechanisms
Installation note:
Requires periodic lubrication (ISO VG32 hydraulic oil recommended).
Avoid side-load forces exceeding 30N. Locking screws should be torqued
to 1.2N·m±10% after final position adjustment.
Performance Features:
- Dual-shaft anti-torsion design prevents angular deviation
- Hard-anodized surface treatment (25μm thickness)
- Pre-loaded linear bearings for zero backlash
- Stainless steel scraper seals for dust prevention
| Property | Property Value |
|---|---|
| sku | TCMJ20X175-100S |
| Adjustable Stroke | 100mm |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | PT1/8 |
| Magnet | S-Magnetic |
| Cushion Type | Bumper Pad |
| Bore Diameter | <20mm> |
| Stroke | 175mm |
