Airtac TCMJ Three-Axis Adjustable Cylinder TCMJ20X25-10S
$96.07
Regular price
$103.57
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
TCMJ20X25-10S
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
1. Complies with JIS standards;
2. Dual guide rods manufactured from specialized bearing steel, guided by linear ball bearings or bronze sliding bearings, delivering exceptional resistance to torsion and lateral loads.★Note: Linear ball bearings: Ideal for lifting applications requiring high precision, heavy load capacity, and low-friction movement. Bronze sliding bearings: Specially engineered for radial load applications like braking systems, offering over twice the lateral impact resistance of standard brake cylinders with enhanced torsional rigidity.
3. Integrated design combines driving unit and guiding mechanism within a single body, eliminating additional accessories while providing compact dimensions and adjustable intake ports for flexible installation;
4. Precision positioning holes on base surface, rear end face, and mounting plate (refer to PA holes and XX marked holes in outline drawing) ensure high-accuracy alignment for critical applications;
5. Four sensor grooves on body enable multiple sensor mounting configurations;
6. Proprietary body structure supports multi-orientation mounting solutions;
Category: Adjustable Cylinders | Brand: AIRTAC | Series: TCMJ
Installation notes:
(1) Use lock nuts after fine-tuning to prevent drift.
(2) Lubricate with ISO VG32 hydraulic oil before initial operation.
(3) Maximum 0.5mm parallel misalignment allowed during mounting.
Critical parameters:
2. Dual guide rods manufactured from specialized bearing steel, guided by linear ball bearings or bronze sliding bearings, delivering exceptional resistance to torsion and lateral loads.★Note: Linear ball bearings: Ideal for lifting applications requiring high precision, heavy load capacity, and low-friction movement. Bronze sliding bearings: Specially engineered for radial load applications like braking systems, offering over twice the lateral impact resistance of standard brake cylinders with enhanced torsional rigidity.
3. Integrated design combines driving unit and guiding mechanism within a single body, eliminating additional accessories while providing compact dimensions and adjustable intake ports for flexible installation;
4. Precision positioning holes on base surface, rear end face, and mounting plate (refer to PA holes and XX marked holes in outline drawing) ensure high-accuracy alignment for critical applications;
5. Four sensor grooves on body enable multiple sensor mounting configurations;
6. Proprietary body structure supports multi-orientation mounting solutions;
Category: Adjustable Cylinders | Brand: AIRTAC | Series: TCMJ
AirTAC TCMJ20X25-10S 3-Axis Adjustable Cylinder Specifications
- Model: TCMJ20X25-10S
- Type: 3-axis adjustable cylinder (mechanical lock type)
- Bore size: 20mm
- Stroke: 25mm
- Adjustable stroke: ±5mm (total 10mm compensation)
- Operating pressure: 0.05–0.9 MPa
- Temperature range: -10℃ to 80℃
- Port size: M5×0.8 (dual ports on each axis)
- Mounting style: Standard flange with 4×M5 threaded holes
- Rod material: Chrome-plated steel
- Tube material: Anodized aluminum alloy
- Seal type: NBR wear-resistant seals
- Weight: 0.68kg ±3%
- Dimensions: 110mm(L) × 42mm(W) × 42mm(H)
- Positioning accuracy: ±0.2mm (after adjustment)
- Max lateral load: 15N
- Cushioning: Adjustable rubber buffer
Precision multi-axis positioning cylinder with mechanical locking mechanism, enabling micron-level adjustments via three orthogonal adjustment screws (X/Y/Z axes). Features dual-port design for bidirectional control and integrated mounting flanges. Includes anti-rotation guide for stable linear motion under side loads.
Typical Applications:
- Precision fixture alignment in CNC machining centers
- Optical component positioning systems
- 3D printer nozzle calibration mechanisms
- Semiconductor wafer handling robots
- Automated inspection equipment alignment
Installation notes:
(1) Use lock nuts after fine-tuning to prevent drift.
(2) Lubricate with ISO VG32 hydraulic oil before initial operation.
(3) Maximum 0.5mm parallel misalignment allowed during mounting.
Critical parameters:
- Do NOT exceed 300mm/s piston speed
- Max cycle rate: 120 cycles/minute
- Requires 5μm filtered air (40μm minimum without lubricator)
| Property | Property Value |
|---|---|
| sku | TCMJ20X25-10S |
| Adjustable Stroke | <10mm> |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | PT1/8 |
| Magnet | S-Magnetic |
| Cushion Type | Bumper Pad |
| Bore Diameter | <20mm> |
| Stroke | <25 mm> |
