Airtac TDH Stop Cylinder TDH20X15SLF
2. Reinforced piston rod design significantly enhances lateral impact resistance capability;
3. Heavy-duty TDH series features integrated oil cushioning or adjustable hydraulic shock absorbers to reliably absorb kinetic energy during impact;
4. Lever-type roller mechanism incorporates a self-locking device that prevents arm rebound and unintended push-back on blocked objects;
5. Multiple configurations and standardized specifications available for customized application requirements.
Category: Stop Cylinders , Brand: AIRTAC , Series: TDH
AirTAC TDH Series Blocking Cylinder TDH20X15SLF Specifications
- Model: TDH20X15SLF
- Type: Double-acting blocking cylinder with magnetic piston
- Bore size: Ø20mm
- Stroke: 15mm (±1mm)
- Operating pressure: 0.1–0.8 MPa
- Port size: M5x0.8 (standard) with G1/8 adapter option
- Cushioning: Adjustable air cushion at both ends
- Piston speed: 50–800 mm/s
- Ambient temperature: -20℃ to 80℃
- Seal material: NBR (nitrile rubber)
- Repeat accuracy: ±0.5mm
- Mounting style: Front flange (ISO 15552 standard)
- Weight: 0.48kg (without accessories)
- Dimensions: 130mm(L) × 34mm(W) × 34mm(H) (fully retracted)
- Protection rating: IP40 (dust protected)
- Magnet type: Samarium cobalt (temperature resistant)
High-precision mechanical stop cylinder with integrated position locking mechanism. Features anodized aluminum barrel and chromium-plated piston rod for corrosion resistance. Includes dual magnetic sensors (sensors sold separately) for position feedback. Designed for high-cycle applications with 50,000km service life under normal conditions.
- Workpiece positioning in CNC machine tool changers
- Precision stopping in semiconductor handling robots
- Part ejection control in injection molding machines
- Safety interlocks in automotive assembly lines
- Vertical lifting systems with position hold requirements
Installation notes:
Maintain 0.5mm minimum clearance between stopper and target surface.
Use filtered air (5-40μm) with lubricator (ISO VG32 oil recommended).
For vertical mounting, install exhaust mist separator to prevent oil drain.
| Property | Property Value |
|---|---|
| sku | TDH20X15SLF |
| Port Size | M5×0.8 |
| Proximity Sensor Thread Type | M5×0.5 |
| Magnet | S-Magnetic |
| Bore Diameter | <20mm> |
| Self-locking Function | Self-locking |
| Stroke | <15mm> |
