Airtac TDH Stop Cylinder TDH40X30SK
2. Reinforced piston rod design significantly enhances lateral impact resistance capability;
3. Heavy-duty TDH series features integrated oil cushioning or adjustable hydraulic shock absorbers to reliably absorb kinetic energy during impact;
4. Lever-type roller mechanism incorporates a self-locking device that prevents arm rebound and unintended push-back on blocked objects;
5. Multiple configurations and standardized specifications available for customized application requirements.
Category: Stop Cylinders , Brand: AIRTAC , Series: TDH
AirTAC TDH Series Blocking Cylinder TDH40X30SK Technical Specifications
- Model: TDH40X30SK
- Type: Double-acting linear blocking cylinder
- Bore size: 40mm
- Stroke: 30mm
- Operating pressure: 0.05–1.0 MPa
- Piston speed: 50–800 mm/s
- Cushioning: Adjustable rubber buffer (both ends)
- Port size: M5x0.8 (standard) with NPT1/8 adaptor optional
- Operating temperature: -10℃ to 80℃
- Seal material: NBR (Nitrile) with wear-resistant ring
- Body material: Aluminum alloy (anodized surface)
- Rod material: Chrome-plated steel
- Mounting type: Basic type (axial foot mounting holes)
- Weight: 0.98 kg ±5%
- Dimensions: 180mm(L) × 56mm(W) × 56mm(H) (extended length)
- Retracted length: 150mm
- Repeat positioning accuracy: ±0.2mm
- Protection rating: IP54 (standard sealing)
High-precision mechanical blocking cylinder with integrated shock absorption, designed for precision stopping applications in automated systems. Features dual-position magnetic sensor slots (inductive sensors not included) and anti-rotation mechanism for stable load handling. Optimized for vertical or horizontal installation with 2x M5 mounting holes on mounting foot.
- Conveyor line product positioning gates
- Robotic arm end-effector tool changers
- CNC machine part clamping systems
- Automotive assembly line buffer stops
- Packaging machine product counting stations
Installation note:
Lubricate with ISO VG32 hydraulic oil before initial use.
For vertical mounting, install with rod facing downward to prevent
piston seal wear. Maintain 20mm clearance around cylinder body
for heat dissipation during continuous operation.
| Property | Property Value |
|---|---|
| sku | TDH40X30SK |
| Port Size | PT1/8 |
| Proximity Sensor Thread Type | M5×0.5 |
| Magnet | S-Magnetic |
| Bore Diameter | <40mm> |
| Self-locking Function | Non Self-locking |
| Stroke | 30mm |
