Airtac TDH Stop Cylinder TDH50X30K
2. Reinforced piston rod design significantly enhances lateral impact resistance capability;
3. Heavy-duty TDH series features integrated oil cushioning or adjustable hydraulic shock absorbers to reliably absorb kinetic energy during impact;
4. Lever-type roller mechanism incorporates a self-locking device that prevents arm rebound and unintended push-back on blocked objects;
5. Multiple configurations and standardized specifications available for customized application requirements.
Category: Stop Cylinders , Brand: AIRTAC , Series: TDH
AirTAC TDH Series Blocking Cylinder TDH50X30K Specifications
- Model: TDH50X30K
- Type: Double-acting linear blocking cylinder
- Bore size: 50mm
- Stroke: 30mm (±1mm tolerance)
- Operating pressure: 0.1–0.8 MPa
- Cushioning: Adjustable pneumatic cushion (both ends)
- Mounting style: Standard ISO 15552 front flange with accessory mounting grooves
- Port size: G1/8 (NPT1/8 optional)
- Operating temperature: -20℃ to 80℃
- Rod material: Hard chrome-plated steel
- Tube material: Anodized aluminum alloy
- Seal material: NBR (Nitrile rubber)
- Repeat positioning accuracy: ±0.5mm
- Protection rating: IP40 (IP67 with optional wiper)
- Weight: 1.56kg (without accessories)
- Dimensions: 180mm(L) × 50mm(Bore diameter) × 63mm(Mounting height)
High-precision blocking cylinder designed for industrial stopping applications requiring controlled deceleration. Features dual-layer wear-resistant seals and anti-rotation mechanism for stable vertical/horizontal operation. Integrated magnet slots (K version) enable sensor mounting for position feedback. Pre-lubricated for maintenance-free operation under standard conditions.
- Assembly line workpiece positioning gates
- Pallet stop systems in conveyor automation
- Robotic pick-and-place buffer stations
- Sheet metal processing equipment stoppers
- Packaging machine product counting mechanisms
Installation note:
Maintain 0.5-1mm clearance between blocking rod and target surface during setup.
Use shock absorber pads for impact forces exceeding 50N. Lubricate guide shafts every
500km of cumulative travel in high-cycle applications.
| Property | Property Value |
|---|---|
| sku | TDH50X30K |
| Port Size | PT1/8 |
| Proximity Sensor Thread Type | M8×1.0 |
| Magnet | Non-magnetic |
| Bore Diameter | <50mm> |
| Self-locking Function | Non Self-locking |
| Stroke | 30mm |
