Airtac TDH Stop Cylinder TDH50X30SK
2. Reinforced piston rod design significantly enhances lateral impact resistance capability;
3. Heavy-duty TDH series features integrated oil cushioning or adjustable hydraulic shock absorbers to reliably absorb kinetic energy during impact;
4. Lever-type roller mechanism incorporates a self-locking device that prevents arm rebound and unintended push-back on blocked objects;
5. Multiple configurations and standardized specifications available for customized application requirements.
Category: Stop Cylinders , Brand: AIRTAC , Series: TDH
AirTAC TDH Series Blocking Cylinder TDH50X30SK Technical Details
- Model: TDH50X30SK
- Type: Double-acting twin piston rod blocking cylinder
- Bore size: Ø50 mm
- Stroke: 30 mm (adjustable cushion)
- Operating pressure: 0.1–0.8 MPa
- Temperature range: -20℃ to 80℃
- Port size: M5x0.8 (standard) / NPT1/8 (optional)
- Piston rod material: Hard chrome-plated steel
- Tube material: Anodized aluminum alloy
- Seal type: NBR rubber (FDA compliant option available)
- Mounting: Front flange MF1 (ISO 15552 compatible)
- Position detection: Built-in magnet for sensor mounting
- Cushioning: Adjustable pneumatic cushion + shock absorber
- Weight: 1.45 kg ±2%
- Dimensions: 200mm(L) × 68mm(W) × 58mm(H)
- Protection class: IP54 (standard) / IP67 (optional)
- Max thrust: 157N @0.5MPa
High-precision stopping cylinder with dual-piston stabilization technology, featuring symmetrical force distribution for ultra-stable workpiece positioning. The TDH50X30SK incorporates anti-rotation guidance and cross-roller bearing support, ensuring ≤±0.1mm repeat positioning accuracy even under side load conditions. Special SK variant includes hardened contact surfaces (HRC 45-50) for metal-on-metal impact resistance.
- Automotive assembly line pallet stops
- PCB conveyor precision positioning systems
- Robotic welding fixture clamping mechanisms
- High-speed packaging machine product gates
- Pharmaceutical vial sorting buffer stations
Installation guidelines:
Maintain perpendicular alignment between cylinder axis and blocking surface (±0.5° max deviation).
Use shock-absorbing pads on both end covers when cycle rate exceeds 120 CPM. Lubricate with ISO VG32
pneumatic oil if operating below -10℃.
| Property | Property Value |
|---|---|
| sku | TDH50X30SK |
| Port Size | PT1/8 |
| Proximity Sensor Thread Type | M8×1.0 |
| Magnet | S-Magnetic |
| Bore Diameter | <50mm> |
| Self-locking Function | Non Self-locking |
| Stroke | 30mm |
