Airtac TDH Stop Cylinder TDH80X40KF
2. Reinforced piston rod design significantly enhances lateral impact resistance capability;
3. Heavy-duty TDH series features integrated oil cushioning or adjustable hydraulic shock absorbers to reliably absorb kinetic energy during impact;
4. Lever-type roller mechanism incorporates a self-locking device that prevents arm rebound and unintended push-back on blocked objects;
5. Multiple configurations and standardized specifications available for customized application requirements.
Category: Stop Cylinders , Brand: AIRTAC , Series: TDH
AirTAC TDH Series Stopper Cylinder TDH80X40KF Technical Details
- Model: TDH80X40KF
- Type: Double-acting rodless stopping cylinder
- Bore size: 80mm (ISO standard)
- Stroke: 40mm (±2mm adjustable)
- Operating pressure: 0.05-1.0 MPa
- Cushioning: Adjustable rubber buffer + external shock absorber
- Temperature range: -20℃ to 80℃
- Material: Stainless steel piston rod, aluminum alloy barrel
- Port size: G3/8 (NPT1/2 optional)
- Mounting: Standard ISO 15552 foot mounting
- Weight: 3.8kg (without accessories)
- Dimensions:
- Body length: 328mm (retracted)
- Total length: 368mm (extended)
- Width: 98mm (mounting base)
- Height: 125mm (including sensor slots)
- Repeat accuracy: ±0.5mm
- Max thrust: 1,960N @ 0.6MPa
- Sensor compatibility: M9 Proximity (2 built-in slots)
High-precision stopping cylinder with dual-position locking mechanism, featuring wear-resistant SEBS seals and corrosion-resistant anodized surfaces. The TDH80X40KF's through-shaft design enables precise mechanical stops with position memory function, capable of absorbing 15J impact energy. Requires 5μm filtered air with ISO VG32 lubricant.
- Automotive assembly line pallet stoppers
- Robotic welding fixture positioning
- Pharmaceutical blister packaging indexing
- LCD panel transfer buffer stations
- Battery module press-fit positioning
Installation guidelines:
Mount horizontally with ±1° tolerance. Allow 50mm clearance for shock absorber extension.
Perform lubrication every 500km of travel. Avoid side-load exceeding 150N.
| Property | Property Value |
|---|---|
| sku | TDH80X40KF |
| Port Size | PT1/4 |
| Proximity Sensor Thread Type | M8×1.0 |
| Magnet | Non-magnetic |
| Bore Diameter | 80 mm |
| Self-locking Function | Self-locking |
| Stroke | <40mm> |
