Airtac TTG Stopper Cylinder TTG32X15SB
2. Reinforced piston rod design enhances lateral load resistance capability;
3. Adjustable mounting height with multiple rod end configurations. Models equipped with oil cushioning devices deliver superior buffering performance;
4. Lever-type roller mechanism incorporates a self-locking feature to prevent arm rebound and unintended object pushback;
5. Multiple series and specifications available for customized solutions.
Category: Stopper Cylinder | Brand: AIRTAC | Series: TTG
AirTAC TTG Series Stopper Cylinder TTG32X15SB Technical Details
- Model: TTG32X15SB
- Type: Compact double-acting stopper cylinder with built-in magnet
- Bore size: Ø32mm
- Stroke: 15mm (±1mm tolerance)
- Operating pressure: 0.1-0.8 MPa
- Port size: M5x0.8 (Standard), G1/8 optional
- Cushion type: Adjustable rubber buffer
- Piston speed: 50-750 mm/s
- Ambient temperature: -20℃ to +80℃
- Weight: 1.25kg (without accessories)
- Dimensions: 115mm(L) × 50mm(W) × 50mm(H)
- Rod material: Chrome-plated steel (S45C)
- Tube material: Aluminum alloy (Al6063-T5)
- Seal material: NBR (Nitrile rubber)
- Repeat accuracy: ±0.5mm
- Protection rating: IP65 (Dust-tight & protected against water jets)
- Mounting type: Square flange with 4xM5 threaded holes
High-precision mechanical stopper cylinder designed for precision positioning and workpiece blocking in automated systems. Features integrated magnetic piston for position feedback (requires external sensor). The TTG series incorporates dual adjustable cushions to minimize impact shock at stroke ends, with anodized aluminum construction for corrosion resistance.
- Conveyor line workpiece positioning gates
- Assembly machine part alignment systems
- Packaging equipment product counting stations
- Robotic palletizing end-effector stoppers
- CNC machine tool fixture positioning
Installation guidelines:
Maintain 0.5mm minimum clearance between stopper face and target surface.
Lubricate with ISO VG32 hydraulic oil before initial use. Avoid side-load forces exceeding 30N.
For vertical mounting, install exhaust mist lubricator upstream.
| Property | Property Value |
|---|---|
| sku | TTG32X15SB |
| Port Size | PT1/8 |
| Magnet | S-Magnetic |
| Bore Diameter | <32 mm> |
| Self-locking Function | Non Self-locking |
| Stroke | <15mm> |
| Blocking Method | Flat Cylinder |
