Airtac TTG Stopper Cylinder TTG32X15SK
2. Reinforced piston rod design enhances lateral load resistance capability;
3. Adjustable mounting height with multiple rod end configurations. Models equipped with oil cushioning devices deliver superior buffering performance;
4. Lever-type roller mechanism incorporates a self-locking feature to prevent arm rebound and unintended object pushback;
5. Multiple series and specifications available for customized solutions.
Category: Stopper Cylinder | Brand: AIRTAC | Series: TTG
AirTAC TTG Series Stopper Cylinder TTG32X15SK Technical Details
- Model: TTG32X15SK
- Type: Double-acting with spring return (blocking mechanism)
- Bore size: Ø32mm
- Stroke: 15mm
- Operating pressure: 0.05–0.9 MPa
- Temperature range: -10℃ to 70℃
- Cushioning: Adjustable rubber buffer
- Mounting type: Standard flange (MF1)
- Port size: M5x0.8 (Rc1/8/NPT1/8 optional)
- Piston rod thread: M10x1.25
- Repeat positioning accuracy: ±0.2mm
- Seal material: Polyurethane (PU) + Nitrile rubber (NBR)
- Protection rating: IP40
- Weight: 1.8kg (including mounting accessories)
- Dimensions: 155mm(L) × 62mm(W) × 62mm(H)
- Max operating speed: 500mm/s
- Lubrication: Pre-lubricated (Oil-free operation possible)
High-precision stopper cylinder with integrated mechanical blocking mechanism, featuring hardened piston rod (HRC 45-50) and anodized aluminum body. Designed for repetitive positioning tasks requiring zero-point locking force up to 320N. Includes magnetic sensor slots for position feedback (sensors sold separately).
- Workpiece positioning in CNC pallet systems
- Precision stopping in SMT component placement
- Safety interlocks in automotive assembly lines
- Carton positioning in high-speed packaging
- Semiconductor wafer handling systems
Installation guidance:
Maintain 0.5-1mm clearance between stopper face and target surface.
Use locknuts (M10) with 12N·m torque specification.
For vertical mounting, install air vent upward.
Requires 5μm filtered air with ISO 8573-1:2010 Class 3.4.2 quality.
| Property | Property Value |
|---|---|
| sku | TTG32X15SK |
| Port Size | PT1/8 |
| Magnet | S-Magnetic |
| Bore Diameter | <32 mm> |
| Self-locking Function | Non Self-locking |
| Stroke | <15mm> |
| Blocking Method | Lever Roller Type |
