Airtac TTG Stopper Cylinder TTG32X15SKF
2. Reinforced piston rod design enhances lateral load resistance capability;
3. Adjustable mounting height with multiple rod end configurations. Models equipped with oil cushioning devices deliver superior buffering performance;
4. Lever-type roller mechanism incorporates a self-locking feature to prevent arm rebound and unintended object pushback;
5. Multiple series and specifications available for customized solutions.
Category: Stopper Cylinder | Brand: AIRTAC | Series: TTG
AirTAC TTG Series Blocking Cylinder TTG32X15SKF Technical Details
- Model: TTG32X15SKF (ISO 6432 compliant)
- Bore size: 32mm (±0.1mm tolerance)
- Stroke: 15mm (adjustable with stopper)
- Operating pressure: 0.1-0.8 MPa
- Buffer type: Adjustable pneumatic cushioning
- Mounting style: Front flange (ISO 15552 standard)
- Port size: G1/8 (NPT1/8 optional)
- Piston material: Anodized aluminum alloy
- Rod material: Chrome-plated steel
- Seal type: SKF self-lubricating seals (NBR+PU compound)
- Temperature range: -20℃ to +80℃
- Weight: 0.62kg (excluding accessories)
- Dimensions: 120mm(L) × 60mm(W) × 80mm(H) (max extended length)
- Repeat accuracy: ±0.2mm
- Max thrust: 210N @0.6MPa
- Protection class: IP67 (dust/water resistant)
Precision blocking cylinder with integrated shock absorption, featuring SKF's proprietary low-friction sealing technology for high-cycle applications. The T-shaped guide rail structure ensures stable vertical load handling. Includes magnetic piston for position sensing compatibility (sensor not included).
- Automated conveyor stop systems
- PCB board positioning in SMT machines
- Automotive part fixturing during welding
- Pharmaceutical blister pack alignment
- Robotic arm workpiece clamping
Installation guidelines:
Maintain 0.05mm maximum misalignment during mounting. Use M6x1.0 mounting screws torqued to 4.5N·m.
Lubricate with ISO VG32 pneumatic oil if operating below -10℃. Requires 5μm filtered air supply.
| Property | Property Value |
|---|---|
| sku | TTG32X15SKF |
| Port Size | PT1/8 |
| Magnet | S-Magnetic |
| Bore Diameter | <32 mm> |
| Self-locking Function | Self-locking |
| Stroke | <15mm> |
| Blocking Method | Lever Roller Type |
