Airtac TTG Stopper Cylinder TTG32X15SR
2. Reinforced piston rod design enhances lateral load resistance capability;
3. Adjustable mounting height with multiple rod end configurations. Models equipped with oil cushioning devices deliver superior buffering performance;
4. Lever-type roller mechanism incorporates a self-locking feature to prevent arm rebound and unintended object pushback;
5. Multiple series and specifications available for customized solutions.
Category: Stopper Cylinder | Brand: AIRTAC | Series: TTG
AirTAC TTG Series Blocking Cylinder TTG32X15SR Technical Details
- Model: TTG32X15SR
- Type: Double-acting with spring return (auto-reset blocking mechanism)
- Bore size: 32mm
- Stroke: 15mm (±0.5mm adjustability)
- Operating pressure: 0.05–1.0 MPa
- Max thrust: 196N at 0.63MPa
- Temperature range: -20℃ to 80℃ (NBR seals)/ -10℃ to 80℃ (FKM seals)
- Cushioning: Adjustable hydraulic buffer (3-stage)
- Mounting: Standard ISO 15552 front flange with 4×M5 threaded holes
- Rod end: M10×1.25 external thread
- Seal material: Standard NBR / Optional FKM
- Operation speed: 50–750mm/s
- Repeat positioning accuracy: ±0.2mm
- Protection rating: IP67 (dust/water resistant)
- Port size: G1/8 (ISO228 standard)
- Weight: 0.82kg (without accessories)
- Dimensions: 165mm(L) × 42mm(W) × 42mm(H) (fully retracted)
High-precision blocking cylinder with integrated mechanical stopper mechanism, featuring a chromium-plated piston rod and anodized aluminum barrel. The TTG32X15SR incorporates a three-stage adjustable cushioning system with locknut presets (soft/medium/hard stops) and visible position indicators. Requires filtered lubricated air (ISO 8573-1:2010 [7:4:4] class) with 20-30μm filtration.
- Precision workpiece positioning in CNC loading systems
- Safety interlocks in automated assembly lines
- Pallet stop mechanisms in conveyor systems
- Tooling fixture clamping in machining centers
- Part ejection control in injection molding machines
Installation protocol:
Mount using M5×12mm SHCS (max 3.5Nm torque). Maintain 0.5-1mm clearance between stopper and target surface. Perform initial 50-100 no-load cycles before commissioning. Lubricate through air supply (ISO VG32 equivalent oil mist, 1 drop/m³).
| Property | Property Value |
|---|---|
| sku | TTG32X15SR |
| Port Size | PT1/8 |
| Magnet | S-Magnetic |
| Bore Diameter | <32 mm> |
| Self-locking Function | Non Self-locking |
| Stroke | <15mm> |
| Blocking Method | Roller Type |
