Airtac TTG Stopper Cylinder TTG32X20K
2. Reinforced piston rod design enhances lateral load resistance capability;
3. Adjustable mounting height with multiple rod end configurations. Models equipped with oil cushioning devices deliver superior buffering performance;
4. Lever-type roller mechanism incorporates a self-locking feature to prevent arm rebound and unintended object pushback;
5. Multiple series and specifications available for customized solutions.
Category: Stopper Cylinder | Brand: AIRTAC | Series: TTG
AirTAC TTG Series Blocking Cylinder TTG32X20K Specifications
- Model: TTG32X20K
- Type: Double-acting blocking cylinder with adjustable cushion
- Bore size: 32mm
- Stroke: 20mm
- Operating pressure: 0.1–0.9 MPa
- Cushion type: Adjustable air cushion (both ends)
- Mounting style: Standard foot mounting (ISO 15552 compliant)
- Port size: 1/4" NPT (G1/8 optional)
- Temperature range: -20℃ to 80℃
- Seal material: NBR (Nitrile rubber)
- Weight: 0.85kg ±3%
- Dimensions: 135mm(L) × 42mm(W) × 42mm(H)
- Rod material: Chrome-plated carbon steel
- Tube material: Anodized aluminum alloy
- Protection rating: IP54
- Piston speed: 50–800 mm/s
High-precision blocking cylinder featuring dual-position mechanical stops for precise mid-stroke halting. The TTG32X20K incorporates wear-resistant seals and hardened guide rings for 5,000km+ service life. Requires 5μm filtered compressed air (ISO 8573-1 class 3) with lubrication (ISO VG32 or equivalent).
- Workpiece positioning in automotive assembly lines
- Carton orientation control in packaging machinery
- PCB board retention during soldering processes
- Pallet transfer blocking in logistics systems
- Glass panel temporary fixation in display manufacturing
Installation guidelines:
Align blocking pins within 0.2mm tolerance. Lubricate guide shafts monthly with
ISO VG32 oil. Adjust cushion screws clockwise to increase damping force.
Maximum side load: 15N at mid-stroke position.
| Property | Property Value |
|---|---|
| sku | TTG32X20K |
| Port Size | PT1/8 |
| Magnet | Non-magnetic |
| Bore Diameter | <32 mm> |
| Self-locking Function | Non Self-locking |
| Stroke | <20mm> |
| Blocking Method | Lever Roller Type |
