Airtac TTG Stopper Cylinder TTG32X20SB
2. Reinforced piston rod design enhances lateral load resistance capability;
3. Adjustable mounting height with multiple rod end configurations. Models equipped with oil cushioning devices deliver superior buffering performance;
4. Lever-type roller mechanism incorporates a self-locking feature to prevent arm rebound and unintended object pushback;
5. Multiple series and specifications available for customized solutions.
Category: Stopper Cylinder | Brand: AIRTAC | Series: TTG
AirTAC TTG Series Blocking Cylinder TTG32X20SB Technical Specifications
- Model: TTG32X20SB
- Type: Compact profile double-acting blocking cylinder
- Bore size: 32mm (±0.1mm tolerance)
- Stroke: 20mm (adjustable via mechanical stopper)
- Operating pressure: 0.1–0.8 MPa
- Cushioning type: Adjustable rubber buffer (both ends)
- Mounting type: Standard foot mounting (MF1) with alternative flange options
- Temperature range: -20℃ to 80℃ (NBR seals)
- Material: Aluminum alloy cylinder tube, hardened stainless steel piston rod
- Port size: M5x0.8 (G1/8 adapter available)
- Rod thread: M10x1.25 (external)
- Weight: 1.8kg (without accessories)
- Dimensions: 150mm(L) × 32mm(W) × 32mm(H) (minimum retracted length)
- Protection class: IP54 (standard), IP67 with optional wiper seal
- Max thrust: 225N at 0.6MPa
- Lubrication: Pre-lubricated (recommended relubrication every 500km stroke)
The TTG32X20SB features a unique wedge-block mechanism with precision ground guide rails, providing exceptional lateral load resistance (up to 150N side force). Its anti-rotation design maintains position accuracy (±0.2mm repeatability) in high-vibration environments. The anodized surface treatment enhances corrosion resistance for humid or mildly corrosive environments.
- Automated conveyor line product positioning
- Robotic welding fixture clamping
- CNC machine tool safety interlocks
- Pharmaceutical packaging material handling
- Battery assembly press mechanisms
Installation guidelines:
Maintain 0.05mm maximum misalignment during mounting. Use locknuts with 12-15N·m torque.
For vertical installations, install air vents upward. Lubricate with ISO VG32 hydraulic oil.
Critical note:
Always install downstream speed controllers (ASC-02 recommended) to prevent piston rod
overshoot. Requires 5μm filtered air with dew point -20℃ below ambient temperature.
| Property | Property Value |
|---|---|
| sku | TTG32X20SB |
| Port Size | PT1/8 |
| Magnet | S-Magnetic |
| Bore Diameter | <32 mm> |
| Self-locking Function | Non Self-locking |
| Stroke | <20mm> |
| Blocking Method | Flat Cylinder |
