Airtac TTG Stopper Cylinder TTG32X20SKF
$104.44
Regular price
$111.94
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
TTG32X20SKF
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
TTG Stopper Cylinder
1. Compliant with JIS (Japanese Industrial Standards) specifications;
2. Reinforced piston rod design enhances lateral load resistance capability;
3. Adjustable mounting height with multiple rod end configurations. Models equipped with oil cushioning devices deliver superior buffering performance;
4. Lever-type roller mechanism incorporates a self-locking feature to prevent arm rebound and unintended object pushback;
5. Multiple series and specifications available for customized solutions.
Category: Stopper Cylinder | Brand: AIRTAC | Series: TTG
Installation protocol:
Align stopper surfaces within 0.05mm parallelism tolerance. Lubricate with ISO VG32 pneumatic oil during initial setup.
Magnetic switch (optional) requires 2mm gap adjustment for position feedback.
2. Reinforced piston rod design enhances lateral load resistance capability;
3. Adjustable mounting height with multiple rod end configurations. Models equipped with oil cushioning devices deliver superior buffering performance;
4. Lever-type roller mechanism incorporates a self-locking feature to prevent arm rebound and unintended object pushback;
5. Multiple series and specifications available for customized solutions.
Category: Stopper Cylinder | Brand: AIRTAC | Series: TTG
AirTAC TTG Series Blocking Cylinder TTG32X20SKF Specifications
- Model: TTG32X20SKF
- Type: Compact double-acting blocking cylinder
- Bore size: Ø32mm (±0.1mm manufacturing tolerance)
- Stroke: 20mm (adjustable with stopper mechanism)
- Operating pressure: 0.05–1.0 MPa
- Cushioning: Adjustable rubber buffer + shock absorber
- Mounting: Standard MF2 (ISO 15552 mounting interfaces)
- Port size: M5x0.8 (dual ports for forward/return strokes)
- Temperature range: -10℃ to 80℃ (dry air required below 0℃)
- Seal material: HNBR (Hydrogenated Nitrile) with wear-resistant ring
- Protection rating: IP54 (dust-protected & splash-resistant)
- Weight: 580g ±2% (excluding accessories)
- Dimensions: 150mm(L) × 45mm(W) × 45mm(H) (stroke extended)
High-precision blocking cylinder with integrated mechanical stopper and position-lock capability. Features anti-rotation design for stable load handling and SMCR (Self-Maintaining Cylinder Rod) technology for reduced seal wear. Requires ISO 8573-1:2010 [4:4:3] class compressed air.
Industrial Applications:
- Automated conveyor line workpiece positioning
- Robotic arm end-effector force control
- CNC machine tool fixture locking
- Pharmaceutical blister pack quality control stations
- Lithium battery stacking pressure regulation
Installation protocol:
Align stopper surfaces within 0.05mm parallelism tolerance. Lubricate with ISO VG32 pneumatic oil during initial setup.
Magnetic switch (optional) requires 2mm gap adjustment for position feedback.
| Property | Property Value |
|---|---|
| sku | TTG32X20SKF |
| Port Size | PT1/8 |
| Magnet | S-Magnetic |
| Bore Diameter | <32 mm> |
| Self-locking Function | Self-locking |
| Stroke | <20mm> |
| Blocking Method | Lever Roller Type |
