Airtac TTG Stopper Cylinder TTG32X20SR
2. Reinforced piston rod design enhances lateral load resistance capability;
3. Adjustable mounting height with multiple rod end configurations. Models equipped with oil cushioning devices deliver superior buffering performance;
4. Lever-type roller mechanism incorporates a self-locking feature to prevent arm rebound and unintended object pushback;
5. Multiple series and specifications available for customized solutions.
Category: Stopper Cylinder | Brand: AIRTAC | Series: TTG
AirTAC TTG Series Stopper Cylinder TTG32X20SR Technical Details
- Model: TTG32X20SR
- Type: Double-acting non-rotating rod stopper cylinder
- Bore size: 32mm
- Stroke: 20mm (±1mm tolerance)
- Operating pressure: 0.05–1.0 MPa
- Cushioning: Adjustable air cushion (both ends)
- Mounting types: Front flange (standard), rear flange, or side-mount options
- Piston rod material: SUS304 stainless steel
- Tube material: Aluminum alloy with hard anodizing
- Seal material: NBR (Nitrile rubber)
- Temperature range: -20℃ to 80℃
- Weight: 1.8kg (with standard accessories)
- Dimensions: 200mm(L) × 80mm(W) × 80mm(H) (at full retraction)
- Max thrust: 231N @ 0.63MPa
- Speed range: 50–800mm/s
- Sensor compatibility: Built-in magnet for proximity switch (PNP/NPN configurable)
- ISO standard: 6432
High-precision stopper cylinder with anti-rotation mechanism, designed for precise positioning and workpiece stopping in automated systems. Features dual guide rods for enhanced stability and adjustable shock absorption. Optional rubber bumper pads available for noise reduction (85dB max operation noise).
- Conveyor line product positioning in electronics assembly
- Automotive part alignment in robotic welding stations
- Carton stopping mechanisms in packaging machinery
- Precision component insertion in semiconductor manufacturing
- Workpiece clamping in CNC machine tooling
Installation requirements:
Maintain parallel alignment within 0.2mm/m during mounting. Use M6x1.0 mounting screws (Grade 8.8 or higher).
Lubricate with ISO VG32 pneumatic oil if operating below -10℃. Requires 5μm filtered air with dew point -20℃ below ambient.
| Property | Property Value |
|---|---|
| sku | TTG32X20SR |
| Port Size | PT1/8 |
| Magnet | S-Magnetic |
| Bore Diameter | <32 mm> |
| Self-locking Function | Non Self-locking |
| Stroke | <20mm> |
| Blocking Method | Roller Type |
