Airtac TTH Stopper Cylinder TTH20X15SL
2、Reinforced piston rod design effectively enhances impact resistance performance;
3、Heavy-duty stopping cylinders integrate hydraulic shock absorbers or adjustable hydraulic cushioning devices for reliable energy absorption;
4、Lever-type roller mechanism with self-locking system prevents arm rebound from pushing back the stopped object;
5、Multiple series and specifications available for customized application requirements.
Category: Stopping Cylinders , Brand: AirTAC , Series: TTH
AirTAC TTH Series Stopper Cylinder TTH20X15SL Technical Details
- Model: TTH20X15SL
- Type: Double-acting compact stopper cylinder
- Bore size: 20mm
- Stroke: 15mm
- Operating pressure: 0.1-0.8 MPa
- Cushion type: Adjustable rubber buffer
- Mounting style: Standard foot & front flange
- Port size: M5x0.8 (dual ports)
- Temperature range: -10℃ to 70℃
- Material: Aluminum alloy body, NBR seals
- Weight: 0.52kg (bare cylinder)
- Dimensions: 80mm(L) × 34mm(W) × 34mm(H)
- Rod thread: M6×1.0 external thread
- Repeat accuracy: ±0.2mm
- Max thrust: 63N @0.5MPa
- Piston speed: 50-700mm/s
High-precision mechanical stopper with integrated cylinder design, featuring anodized corrosion-resistant surface and dual-position magnetic sensing slots. The T-shaped guide rail structure ensures stable linear motion, with cushion adjustment screws preventing impact damage at stroke ends. Requires ISO 8573-1:2010 Class 3 compressed air.
- Conveyor line product positioning gates
- PCB handling machine stopper mechanisms
- Automated assembly station part alignment
- Packaging machine tray height limiters
- Robotic workcell safety interlocks
Installation note:
Lubricate with ISO VG32 turbine oil before initial use. Maintain 0.3mm minimum clearance between stopper face and workpiece. For vertical mounting, install with rod end downward to prevent seal wear.
| Property | Property Value |
|---|---|
| sku | TTH20X15SL |
| Port Size | M5×0.8 |
| Proximity Sensor Thread Type | M5×0.5 |
| Magnet | S-Magnetic |
| Bore Diameter | <20mm> |
| Self-locking Function | Non Self-locking |
| Stroke | <15mm> |
