Airtac TTH Stopper Cylinder TTH25X15SLF
2、Reinforced piston rod design effectively enhances impact resistance performance;
3、Heavy-duty stopping cylinders integrate hydraulic shock absorbers or adjustable hydraulic cushioning devices for reliable energy absorption;
4、Lever-type roller mechanism with self-locking system prevents arm rebound from pushing back the stopped object;
5、Multiple series and specifications available for customized application requirements.
Category: Stopping Cylinders , Brand: AirTAC , Series: TTH
AirTAC TTH Series Stopper Cylinder TTH25X15SLF Specifications
- Model: TTH25X15SLF
- Type: Double-acting rodless blocking cylinder
- Bore size: Ø25mm
- Stroke: 15mm (customizable 5-200mm)
- Operating pressure: 0.15-0.8 MPa
- Operating temperature: -20℃ to 80℃
- Port size: M5x0.8 (standard) or NPT1/8 optional
- Cushion type: Adjustable rubber buffer
- Seal material: NBR (Nitrile rubber)
- Piston material: Aluminum alloy with hard anodizing
- Rod material: Stainless steel SUS304
- Position detection: Built-in magnet for sensor mounting
- Weight: 0.62kg ±2%
- Dimensions: 156mm(L) × 34mm(W) × 34mm(H)
- ISO standard: 6432 compliant
- Protection rating: IP54 (dust protected, water splashed)
Precision rodless cylinder with integrated mechanical stopper mechanism, featuring a unique wedge-shaped brake structure that achieves 3x higher holding force than standard cylinders. The T-shaped slot design enables direct mounting of workpieces or tooling plates. Optimized for high-cycle applications requiring positional accuracy within ±0.2mm.
- Precision workpiece positioning in CNC machine tools
- Pallet locking in automated assembly lines
- Safety interlocks in robotic workcells
- Vertical axis braking in material handling systems
- PCB fixture clamping in electronics manufacturing
Installation note:
Ensure proper alignment of stopper mechanism before air supply connection.
Requires regular lubrication (ISO VG32 hydraulic oil recommended) every
500,000 cycles. Maximum side load capacity: 30N at full extension.
| Property | Property Value |
|---|---|
| sku | TTH25X15SLF |
| Port Size | M5×0.8 |
| Proximity Sensor Thread Type | M5×0.5 |
| Magnet | S-Magnetic |
| Bore Diameter | <25 mm> |
| Self-locking Function | Self-locking |
| Stroke | <15mm> |
