Airtac TTH Stopper Cylinder TTH32X20SK
2、Reinforced piston rod design effectively enhances impact resistance performance;
3、Heavy-duty stopping cylinders integrate hydraulic shock absorbers or adjustable hydraulic cushioning devices for reliable energy absorption;
4、Lever-type roller mechanism with self-locking system prevents arm rebound from pushing back the stopped object;
5、Multiple series and specifications available for customized application requirements.
Category: Stopping Cylinders , Brand: AirTAC , Series: TTH
AirTAC TTH Series Blocking Cylinder TTH32X20SK Specifications
- Model: TTH32X20SK
- Type: Double-acting, rod-type blocking cylinder
- Bore size: 32mm
- Stroke: 20mm
- Operating pressure: 0.1–0.8 MPa
- Cushioning: Adjustable pneumatic cushion (both ends)
- Mounting style: Foot-mount (Standard), optional flange or front flange
- Port size: PT1/8 (G1/8 or NPT1/8 optional)
- Operating temperature: -20℃ to 80℃
- Material:
- Cylinder tube: Aluminum alloy (hard anodized)
- Piston rod: Stainless steel (SUS304)
- Seals: NBR (Nitrile rubber)
- Weight: 1.8kg (excluding accessories)
- Dimensions (L×W×H):
- Retracted length: 150mm
- Extended length: 170mm
- Body width: 52mm
- Mounting base height: 12mm
High-precision blocking cylinder with integrated mechanical stopper mechanism, featuring wear-resistant chromium-plated guide rod and precision ground tube. The TTH32X20SK delivers 420N thrust force at 0.6MPa, with IP54-rated protection against particulate ingress. Includes magnetic piston for position sensing compatibility (sensor not included).
- Precision workpiece positioning in CNC machine tool changers
- Pallet locking in automated assembly lines
- Material handling system stoppers
- Packaging machine product counting stations
- Automotive welding fixture safety interlocks
Installation note:
Lubricate with ISO VG32 hydraulic oil before initial use.
Maintain 0.5mm minimum clearance between stopper face and load surface.
For vertical mounting, use counterbalance valve (optional accessory code: CVQ2-10).
| Property | Property Value |
|---|---|
| sku | TTH32X20SK |
| Port Size | PT1/8 |
| Proximity Sensor Thread Type | M5×0.5 |
| Magnet | S-Magnetic |
| Bore Diameter | <32 mm> |
| Self-locking Function | Non Self-locking |
| Stroke | <20mm> |
