Airtac TTH Stopper Cylinder TTH40X30K
2、Reinforced piston rod design effectively enhances impact resistance performance;
3、Heavy-duty stopping cylinders integrate hydraulic shock absorbers or adjustable hydraulic cushioning devices for reliable energy absorption;
4、Lever-type roller mechanism with self-locking system prevents arm rebound from pushing back the stopped object;
5、Multiple series and specifications available for customized application requirements.
Category: Stopping Cylinders , Brand: AirTAC , Series: TTH
AirTAC TTH Series Stopper Cylinder TTH40X30K Technical Details
- Model: TTH40X30K
- Type: Compact profile rodless stopping cylinder
- Bore size: 40mm
- Stroke: 30mm (±15mm adjustable)
- Operating pressure: 0.05–0.9 MPa
- Cushioning: Adjustable rubber buffer + shock absorber
- Port size: 1/4" NPT (G1/8 optional)
- Mounting: Standard side-mount with M6×1.0 threaded holes
- Ambient temperature: -10℃ to 70℃
- Piston material: Hard anodized aluminum alloy
- Rod material: Chrome-plated steel
- Seals: HNBR (Hydrogenated Nitrile) with wear-resistant guide rings
- Weight: 1.2kg (excluding accessories)
- Dimensions: 156mm(L) × 48mm(W) × 40mm(H)
- Repeat accuracy: ±0.5mm
- Max thrust: 510N @0.6MPa
- Response time: ≤100ms
- Accessories: Built-in magnet for sensor detection (NPN/PNP optional)
High-precision stopping cylinder with integrated shock absorption system, designed for precise workpiece positioning in automated production lines. Features dual-axis alignment structure for enhanced stability and optional magnetic sensor compatibility for position feedback. Maintenance-free design with corrosion-resistant coating for harsh environments.
- Pallet stop mechanisms in conveyor systems
- Precision part positioning in robotic assembly cells
- Workpiece clamping in CNC machine tooling
- Sorting gate control in logistics automation
- Component alignment in electronic assembly lines
Installation guidelines:
Maintain horizontal mounting position with ±2° tolerance. Use regulated dry air supply with 5-50μm filtration.
Lubricate with ISO VG32 turbine oil if manual lubrication required. Allow 0.5-1mm clearance between stopper and workpiece surface.
| Property | Property Value |
|---|---|
| sku | TTH40X30K |
| Port Size | PT1/8 |
| Proximity Sensor Thread Type | M5×0.5 |
| Magnet | Non-magnetic |
| Bore Diameter | <40mm> |
| Self-locking Function | Non Self-locking |
| Stroke | 30mm |
