Airtac TTH Stopper Cylinder TTH40X30SK
2、Reinforced piston rod design effectively enhances impact resistance performance;
3、Heavy-duty stopping cylinders integrate hydraulic shock absorbers or adjustable hydraulic cushioning devices for reliable energy absorption;
4、Lever-type roller mechanism with self-locking system prevents arm rebound from pushing back the stopped object;
5、Multiple series and specifications available for customized application requirements.
Category: Stopping Cylinders , Brand: AirTAC , Series: TTH
AirTAC TTH Series Blocking Cylinder TTH40X30SK Technical Details
- Model: TTH40X30SK
- Type: Double-acting compact blocking cylinder
- Bore size: 40mm
- Stroke: 30mm (customizable up to 300mm)
- Operating pressure: 0.05–1.0 MPa
- Operating temperature: -20℃ to 80℃
- Piston speed: 50–1000 mm/s
- Cushioning: Adjustable air cushion (both ends)
- Mounting type: Basic type (optional foot/flange mounting)
- Port size: Rc1/8 (G1/8 adaptor included)
- Seal material: NBR (nitrile rubber)
- Piston rod material: Chrome-plated steel
- Tube material: Anodized aluminum alloy
- Weight: 1.25kg ±3% (bare cylinder)
- Dimensions:
- Body diameter: 40mm
- Total length (stroke 30mm): 153mm
- Rod end thread: M12×1.25
- Mounting hole spacing: 32mm (standard pattern)
High-precision industrial blocking cylinder featuring dual-position magnetic sensing slots (2×M5 slots) for position feedback. Anti-rotation design with integrated guide mechanism ensures stable linear motion. Corrosion-resistant construction with IP65 protection rating. Optional grease pre-lube for food-grade applications (FDA-compliant lubricant).
- Automated conveyor line stopper mechanisms
- CNC machine tool clamping systems
- Robotic welding fixture positioning
- Packaging machine product height detection gates
- Automotive assembly line part orientation control
Installation guidelines:
Maintain 0.5mm minimum clearance between magnetic sensor and cylinder body.
For vertical mounting, install rod end downward to prevent seal wear.
Lubricate every 500,000 cycles using ISO VG32 hydraulic oil.
| Property | Property Value |
|---|---|
| sku | TTH40X30SK |
| Port Size | PT1/8 |
| Proximity Sensor Thread Type | M5×0.5 |
| Magnet | S-Magnetic |
| Bore Diameter | <40mm> |
| Self-locking Function | Non Self-locking |
| Stroke | 30mm |
