Airtac TTH Stopper Cylinder TTH50X30SKF
2、Reinforced piston rod design effectively enhances impact resistance performance;
3、Heavy-duty stopping cylinders integrate hydraulic shock absorbers or adjustable hydraulic cushioning devices for reliable energy absorption;
4、Lever-type roller mechanism with self-locking system prevents arm rebound from pushing back the stopped object;
5、Multiple series and specifications available for customized application requirements.
Category: Stopping Cylinders , Brand: AirTAC , Series: TTH
AirTAC TTH Series Blocking Cylinder TTH50X30SKF Full Specifications
- Model: TTH50X30SKF
- Type: Double-acting compact blocking cylinder
- Bore size: 50mm (ISO 6432 standard)
- Stroke: 30mm ±0.5mm tolerance
- Operating pressure: 0.05-0.9 MPa
- Cushioning type: Adjustable air cushion (both ends)
- Mounting style: Front flange (MF1) & rear foot (FC1) combo
- Port size: M5x0.8 (standard) with optional NPT1/8 adapter
- Temperature range: -20℃ to 80℃
- Rod material: Hard chrome-plated steel (HRC 45-50)
- Tube material: Aluminum alloy (anodized surface)
- Seal type: HNBR seals (oil & heat resistant)
- Protection class: IP54 (dust & splash proof)
- Weight: 1.45kg ±3% (without accessories)
- Dimensions: 200mm(L) × 58mm(W) × 58mm(H)
- Max thrust: 1,030N @ 0.63MPa
- Piston speed: 50-800mm/s (optimal range)
High-precision blocking cylinder featuring integrated magnetic field detection and dual-position locking mechanism. The TTH50X30SKF's compact profile combines with an anti-rotation guide rod design (patented SKF bearing structure) for precise linear motion control. Special shock-absorbing pads reduce impact noise by 15dB compared to standard models.
- Automated part positioning in PCB assembly lines
- Workpiece clamping in CNC rotary tables
- Conveyor gate control in food packaging systems
- Precision alignment in solar panel manufacturing
- Safety interlocks in automotive welding robots
Installation guidelines:
Maintain 0.05mm maximum misalignment during mounting. Apply MIL-PRF-81309F
lubricant quarterly for high-cycle applications (>500k cycles/year).
Avoid side-load exceeding 30N during operation.
| Property | Property Value |
|---|---|
| sku | TTH50X30SKF |
| Port Size | PT1/8 |
| Proximity Sensor Thread Type | M8×1.0 |
| Magnet | S-Magnetic |
| Bore Diameter | <50mm> |
| Self-locking Function | Self-locking |
| Stroke | 30mm |
