Airtac TTH Stopper Cylinder TTH63X30SK
2、Reinforced piston rod design effectively enhances impact resistance performance;
3、Heavy-duty stopping cylinders integrate hydraulic shock absorbers or adjustable hydraulic cushioning devices for reliable energy absorption;
4、Lever-type roller mechanism with self-locking system prevents arm rebound from pushing back the stopped object;
5、Multiple series and specifications available for customized application requirements.
Category: Stopping Cylinders , Brand: AirTAC , Series: TTH
AirTAC TTH Series Blocking Cylinder TTH63X30SK Technical Details
- Model Code: TTH63X30SK
- Type: Double-acting magnetic piston blocking cylinder
- Bore size: Ø63mm (ISO 6432 standard)
- Stroke: 30mm ±0.5mm
- Operating pressure: 0.05-1.0 MPa
- Temperature range: -20℃ to 80℃ (dry air required below 0℃)
- Cushioning type: Adjustable rubber buffer + external shock absorber
- Mounting style: ISO 15552 foot-mounted with reinforced base
- Port size: G1/4 (BSPP thread)
- Piston rod material: Hard chrome-plated SUS420J2 steel
- Seal material: HNBR with wear-resistant guide rings
- Repeat positioning accuracy: ±0.2mm
- Max speed: 500mm/s (with cushion engaged)
- Weight: 2.5kg ±3% (without accessories)
- Dimensions:
- Body length: 190mm (excluding rod)
- Width (mounting base): 80mm
- Height (including rod): 235mm at full extension
- Rod diameter: Ø20mm
Heavy-duty blocking cylinder with integrated mechanical lock mechanism, featuring dual-position magnetic sensors (SK suffix indicates 2-wire PNP output). The TTH63X30SK combines high holding force (up to 1,250N at 0.6MPa) with precision linear motion, utilizing corrosion-resistant coatings and IP67-rated sensor slots. Requires 5-40μm filtered compressed air with ISO VG32 lubricator.
- Automotive assembly line part positioning gates
- Palletizing robot end-effector safety interlocks
- CNC machine tool workpiece clamping systems
- Electronics conveyor emergency stop barriers
- Bottle capping machine pressure retention units
Installation protocol:
Mount horizontally with ≤0.1mm/m alignment tolerance. Engage lock mechanism before system pressurization.
Perform weekly lubrication via integrated grease nipple (M6×1 thread). Sensor cables must use shielded conduits in high EMI environments.
| Property | Property Value |
|---|---|
| sku | TTH63X30SK |
| Port Size | PT1/4 |
| Proximity Sensor Thread Type | M8×1.0 |
| Magnet | S-Magnetic |
| Bore Diameter | 63mm |
| Self-locking Function | Non Self-locking |
| Stroke | 30mm |
