Airtac TTH Stopper Cylinder TTH80X40SKF
2、Reinforced piston rod design effectively enhances impact resistance performance;
3、Heavy-duty stopping cylinders integrate hydraulic shock absorbers or adjustable hydraulic cushioning devices for reliable energy absorption;
4、Lever-type roller mechanism with self-locking system prevents arm rebound from pushing back the stopped object;
5、Multiple series and specifications available for customized application requirements.
Category: Stopping Cylinders , Brand: AirTAC , Series: TTH
AirTAC TTH Series Stopper Cylinder TTH80X40SKF Technical Details
- Model: TTH80X40SKF
- Type: Double-acting stopper cylinder with spring return
- Bore size: 80 mm
- Stroke: 40 mm (Standard) ±1mm tolerance
- Operating pressure: 0.05-1.0 MPa
- Cushioning type: Elastic buffer + external adjustable rubber bumper
- Mounting style: Front/rear flange mounting (ISO 15552 standard)
- Port size: G1/2 (BSPP thread)
- Operating temperature: -20℃ to 80℃
- Piston material: Hard anodized aluminum alloy
- Rod material: Chrome-plated steel (Cr-Mo steel base)
- Seal type: High-grade NBR seals (FDA compliant option available)
- Weight: 3.5 kg ±5% (without accessories)
- Dimensions: 260mm(L) × 95mm(W) × 95mm(H) (Stroke extended state)
- Protection class: IP67 (Dust-tight & protected against immersion)
- Lubrication: Pre-lubricated (Use ISO VG32 hydraulic oil if needed)
The TTH80X40SKF heavy-duty stopper cylinder features dual-position mechanical locking for secure load holding. Its multi-stage buffering system minimizes impact noise (<65dB) while maintaining positioning accuracy of ±0.5mm. The corrosion-resistant design incorporates stainless steel guide rings and triple-lip rod seals for 5,000km+ service life under continuous operation.
- Automotive welding line positioning gates
- Pallet stoppers in automated warehouse shuttle systems
- Press machine safety interlocks
- Food packaging line product separation mechanisms
- Robotic arm end-effector locking devices
Installation tip:
Align within 0.2mm perpendicularity tolerance during mounting.
Use M10x1.5 mounting bolts (Grade 8.8 or higher) with Loctite 243 threadlocker.
Maintain 0.5-1mm clearance between stopper plate and cylinder rod end.
| Property | Property Value |
|---|---|
| sku | TTH80X40SKF |
| Port Size | PT1/4 |
| Proximity Sensor Thread Type | M8×1.0 |
| Magnet | S-Magnetic |
| Bore Diameter | 80 mm |
| Self-locking Function | Self-locking |
| Stroke | <40mm> |
