Airtac TTQ Stopper Cylinder TTQ20X10SR
1. Complies with JIS standards;
2. Reinforced piston rod design significantly enhances impact resistance;
3. Fixed mounting height with multiple rod end configurations - Optional hydraulic shock absorber delivers superior cushioning performance;
4. Lever roller mechanism integrates self-locking device that prevents arm rebound and ensures secure obstruction of target objects;
5. Comprehensive series/specification options for flexible integration into diverse applications.
Category: Stop Cylinders , Brand: AirTAC , Series: TTQ
AirTAC TTQ Series Stopper Cylinder TTQ20X10SR Technical Specifications
- Model: TTQ20X10SR
- Type: Double-acting stopper cylinder with spring return
- Bore size: 20mm
- Stroke: 10mm (±1mm adjustable)
- Operating pressure: 0.1-0.8 MPa
- Operating temperature: -20℃ to 80℃
- Cushioning: Adjustable rubber buffer
- Mounting options: Front flange (FF), side lug (MS1), or foot mounting (MF2)
- Rod thread: M6×1.0 external thread
- Port size: M5×0.8 (G1/8 adapter optional)
- Seal material: NBR (Nitrile rubber)
- Body material: Aluminum alloy (hard anodized)
- Rod material: Stainless steel SUS304
- Weight: 0.68kg (without accessories)
- Dimensions: 100mm(L) × 42mm(W) × 42mm(H) (full extension)
- Protection rating: IP54 (standard), IP67 optional
- Repeat accuracy: ±0.2mm
- Max thrust: 63N @0.5MPa
High-precision mechanical stopper with integrated shock absorption, designed for precision positioning in automated production lines. Features anti-rotation guide mechanism and wear-resistant coating on contact surfaces. The SR variant includes a built-in spring return for fail-safe operation. Requires 5-40μm filtered air with ISO 8573-1:2010 Class 3.4.3 air quality.
- Conveyor line product positioning in packaging machinery
- Workpiece clamping in CNC rotary tables
- Precision stopping in semiconductor handling systems
- Tooling fixture positioning for robotic welding cells
- Carton flap control in box forming machines
Installation note:
Align stopper surface perpendicular to moving objects (max 0.5° tolerance).
Apply silicone-based grease (ISO VG32) to rod every 500,000 cycles.
Maintain 0.3-0.5MPa air pressure for optimal cushioning performance.
| Property | Property Value |
|---|---|
| sku | TTQ20X10SR |
| Port Size | M5×0.8 |
| Magnet | S-Magnetic |
| Bore Diameter | <20mm> |
| Self-locking Function | Non Self-locking |
| Stroke | <10mm> |
| Blocking Method | Roller Type |
