Airtac TTQ Stopper Cylinder TTQ20X15C
1. Complies with JIS standards;
2. Reinforced piston rod design significantly enhances impact resistance;
3. Fixed mounting height with multiple rod end configurations - Optional hydraulic shock absorber delivers superior cushioning performance;
4. Lever roller mechanism integrates self-locking device that prevents arm rebound and ensures secure obstruction of target objects;
5. Comprehensive series/specification options for flexible integration into diverse applications.
Category: Stop Cylinders , Brand: AirTAC , Series: TTQ
AirTAC TTQ20X15C Stopper Cylinder Specifications
- Model: TTQ20X15C
- Type: Double-acting compact stopper cylinder
- Bore size: 20mm
- Stroke: 15mm
- Operating pressure: 0.1–0.8 MPa
- Cushioning: Adjustable pneumatic cushion (both ends)
- Port size: M5x0.8 (standard), G1/8 optional
- Piston material: Aluminum alloy with hard anodized surface
- Rod material: Chrome-plated stainless steel
- Seal type: NBR seals (standard), optional FKM for high temp
- Temperature range: -20℃ to 80℃ (NBR seals)
- Weight: 0.48kg ±2%
- Dimensions: 194mm(L) × 42mm(W) × 38mm(H)
- Mounting types: Fixed (standard), with optional swivel base
- Repeat accuracy: ±0.2mm
- Protection rating: IP54 (standard), IP67 with optional wiper
High-precision stopper cylinder designed for position blocking and workpiece retention in automated systems. Features a space-saving design with integrated shock absorption and wear-resistant construction. The T-slot mounting groove allows flexible integration with sensors or mechanical stops. Requires ISO 8573-1 class 3 or cleaner compressed air.
- Precision part positioning in PCB assembly lines
- Product height verification in quality control stations
- Workpiece clamping during CNC machining processes
- Package alignment systems in logistics sorting machines
- Safety interlocks in robotic work cells
Operation tip:
For optimal performance, maintain air supply pressure above 0.3 MPa during high-cycle
operations (>60 cycles/min). Lubricate using ISO VG32 pneumatic oil if using non-lubricated air.
Avoid side-load forces exceeding 15N to prevent rod deflection.
| Property | Property Value |
|---|---|
| sku | TTQ20X15C |
| Port Size | M5×0.8 |
| Magnet | Non-magnetic |
| Bore Diameter | <20mm> |
| Self-locking Function | Non Self-locking |
| Stroke | <15mm> |
| Blocking Method | Round Type |
