Airtac TTQ Stopper Cylinder TTQ20X15R
1. Complies with JIS standards;
2. Reinforced piston rod design significantly enhances impact resistance;
3. Fixed mounting height with multiple rod end configurations - Optional hydraulic shock absorber delivers superior cushioning performance;
4. Lever roller mechanism integrates self-locking device that prevents arm rebound and ensures secure obstruction of target objects;
5. Comprehensive series/specification options for flexible integration into diverse applications.
Category: Stop Cylinders , Brand: AirTAC , Series: TTQ
AirTAC TTQ20X15R Blocking Cylinder Technical Specifications
- Model: TTQ20X15R
- Type: Compact double-acting blocking cylinder
- Bore size: 20mm
- Stroke: 15mm
- Operating pressure: 0.05–1.0 MPa
- Operating temperature: -10℃ to 70℃
- Cushioning: Adjustable rubber buffer
- Port size: M5×0.8 (dual ports)
- Rod end: External thread M6×1.0
- Piston material: Aluminum alloy with hard anodizing
- Seal material: NBR (nitrile rubber)
- Mounting type: R-type (front flange with side mounting holes)
- Weight: 0.48kg ±2%
- Dimensions: 106mm(L) × 40mm(W) × 40mm(H)
- Protection rating: IP54 (standard dust/moisture resistance)
Precision-engineered blocking cylinder featuring instant-position locking capability through mechanical wedge mechanism. The TTQ20X15R combines 2.5mm/s low-speed stability with 500N maximum lateral blocking force. Enhanced wear resistance through chrome-plated piston rod (2μm thickness) and integrated guide rail design prevents rotational slippage during high-cycle operations.
- PCB conveyor stop gates in electronics manufacturing
- Workpiece positioning in CNC rotary tables
- Carton alignment systems in packaging lines
- Safety interlocks in automotive assembly robots
- Precision fixturing for optical component testing
Installation protocol:
Maintain 0.05mm maximum parallel deviation during rail mounting.
Requires weekly lubrication (VG32 hydraulic oil recommended) with
0.3ml oil supplement per lubrication port. Avoid lateral impact
forces exceeding 150N during operation.
| Property | Property Value |
|---|---|
| sku | TTQ20X15R |
| Port Size | M5×0.8 |
| Magnet | Non-magnetic |
| Bore Diameter | <20mm> |
| Self-locking Function | Non Self-locking |
| Stroke | <15mm> |
| Blocking Method | Roller Type |
