Airtac TTQ Stopper Cylinder TTQ20X15SR
1. Complies with JIS standards;
2. Reinforced piston rod design significantly enhances impact resistance;
3. Fixed mounting height with multiple rod end configurations - Optional hydraulic shock absorber delivers superior cushioning performance;
4. Lever roller mechanism integrates self-locking device that prevents arm rebound and ensures secure obstruction of target objects;
5. Comprehensive series/specification options for flexible integration into diverse applications.
Category: Stop Cylinders , Brand: AirTAC , Series: TTQ
AirTAC TTQ Series Blocking Cylinder TTQ20X15SR Technical Specifications
- Model: TTQ20X15SR
- Type: Double-acting spring return blocking cylinder
- Bore size: Ø20mm
- Stroke: 15mm
- Operating pressure: 0.05–0.8 MPa
- Operating temperature: -10℃ to 80℃
- Cushioning: Adjustable rubber buffer
- Piston rod material: Hard chrome-plated steel
- Tube material: Anodized aluminum alloy
- Seal type: NBR + PU combination
- Port size: M5×0.8 (standard)
- Mounting type: 2×M4 threaded holes (side mounting)
- Weight: 0.82kg ±3%
- Dimensions: 106mm(L) × 34mm(W) × 34mm(H)
- Repeat accuracy: ±0.2mm
- Max lateral load: 35N
- ISO standard: 6432
Precision linear actuator with integrated mechanical blocking mechanism, featuring rapid response (≤0.5s cycle time) and IP54-rated dust/water resistance. The spring-assisted return ensures fail-safe operation during power loss. Requires 40μm filtered air with ISO VG32 lubricant (optional auto-lube systems compatible).
- Conveyor stop systems in packaging lines
- Workpiece positioning in CNC rotary tables
- PCB board clamping in SMT machines
- Robotic arm end-effector tool changers
- Automotive parts assembly fixtures
Installation guidance:
Align piston rod axis within 0.5° deviation. Apply anti-seize compound
(graphite-based recommended) on mounting threads. Perform 10-15
test cycles before full-load operation.
| Property | Property Value |
|---|---|
| sku | TTQ20X15SR |
| Port Size | M5×0.8 |
| Magnet | S-Magnetic |
| Bore Diameter | <20mm> |
| Self-locking Function | Non Self-locking |
| Stroke | <15mm> |
| Blocking Method | Roller Type |
