Airtac TTQ Stopper Cylinder TTQ20X20C
1. Complies with JIS standards;
2. Reinforced piston rod design significantly enhances impact resistance;
3. Fixed mounting height with multiple rod end configurations - Optional hydraulic shock absorber delivers superior cushioning performance;
4. Lever roller mechanism integrates self-locking device that prevents arm rebound and ensures secure obstruction of target objects;
5. Comprehensive series/specification options for flexible integration into diverse applications.
Category: Stop Cylinders , Brand: AirTAC , Series: TTQ
AirTAC TTQ Series Stopper Cylinder TTQ20X20C Technical Specifications
- Model: TTQ20X20C
- Type: Double-acting stopper cylinder with magnetic piston
- Bore size: 20mm
- Stroke: 20mm (Standard) / Customizable up to 100mm
- Installation types: Front flange (FF), Rear flange (RF), Side mount (SM)
- Operating pressure: 0.15–0.8 MPa (21.7–116 PSI)
- Ambient temperature: -20℃ to 80℃ (-4°F to 176°F)
- Cushioning: Adjustable pneumatic cushion
- Material:
- Cylinder tube: Aluminum alloy hard anodized
- Piston rod: Stainless steel (SUS304)
- Seals: Nitrile rubber (NBR) standard / Optional Polyurethane (PU)
- Weight: 0.65kg (1.43lbs) ±3%
- Dimensions:
- Extended length: 200mm (7.87")
- Body diameter: 20mm (0.79")
- Mounting base width: 32mm (1.26")
- Rod end thread: M5×0.8
- Port size: M5×0.8 (1/8" NPT adapter optional)
- Repeat positioning accuracy: ±0.1mm
- Max theoretical force: 56N at 0.6MPa (Extending)
- Protection class: IP54 (Standard) / IP67 (Optional w/rod cover)
Precision stopper cylinder with integrated magnetic field detection, designed for high-cycle positioning and workpiece stopping in automated systems. Features dual sealing technology with wiper ring for contamination resistance. The chrome-plated guide rod ensures smooth linear motion even under side load conditions.
- PCB board positioning in electronics assembly
- Workpiece alignment in automotive engine component lines
- Bottle cap orientation control in bottling machines
- Pallet stop mechanisms in AS/RS warehouses
- Precision part clamping in CNC loading systems
Installation best practices:
Maintain 0.5-1mm clearance between stopper tip and target surface.
Use shock absorber (e.g., ASC-6) for cycles >1Hz. Lubricate with ISO VG32
turbine oil if operating below -10℃. Align within ±0.5° angular deviation.
- Magnetic sensor: D-A93 (PNP output)
- Rod end: ER6×12 shock absorber
- Mounting kit: MFI-20 series brackets
- Protective cover: SCM-20 silicone bellows
| Property | Property Value |
|---|---|
| sku | TTQ20X20C |
| Port Size | M5×0.8 |
| Magnet | Non-magnetic |
| Bore Diameter | <20mm> |
| Self-locking Function | Non Self-locking |
| Stroke | <20mm> |
| Blocking Method | Round Type |
