Airtac TTQ Stopper Cylinder TTQ20X20SB
1. Complies with JIS standards;
2. Reinforced piston rod design significantly enhances impact resistance;
3. Fixed mounting height with multiple rod end configurations - Optional hydraulic shock absorber delivers superior cushioning performance;
4. Lever roller mechanism integrates self-locking device that prevents arm rebound and ensures secure obstruction of target objects;
5. Comprehensive series/specification options for flexible integration into diverse applications.
Category: Stop Cylinders , Brand: AirTAC , Series: TTQ
AirTAC TTQ Series Stopper Cylinder TTQ20X20SB Technical Details
- Model: TTQ20X20SB
- Type: Compact double-acting stopping cylinder
- Bore size: 20mm
- Stroke: 20mm (adjustable cushion)
- Operating pressure: 0.05-1.0 MPa
- Piston rod material: Hardened SCM435 steel
- Barrel material: Aluminum alloy with hard anodizing
- Seal type: NBR rubber seals
- Port size: M5x0.8 (standard) / NPT1/8 optional
- Operating temperature: -10℃ to 80℃
- Mounting style: Axial clamp (standard) / side-mount adapter available
- Repeat accuracy: ±0.5mm
- Weight: 0.68kg (with accessories)
- Dimensions: 108mm(L) × 34mm(W) × 34mm(H) (retracted state)
- Extended length: 128mm (full stroke)
- Cushioning mechanism: Adjustable rubber bumper + air cushion
- Protection rating: IP54 (standard) / IP67 optional
Precision stopping cylinder featuring a dual-diameter piston design for high impact resistance in constrained spaces. The TTQ20X20SB incorporates a hybrid cushioning system combining mechanical shock absorption and pneumatic deceleration, enabling smooth operation at speeds up to 1.5m/s. Its anti-rotation guide structure maintains positional accuracy during repetitive stopping actions.
- Workpiece positioning in PCB assembly lines
- Tooling fixture locking in CNC machining centers
- Carton alignment systems in packaging machinery
- Safety door interlocks for robotic workcells
- Precision stopping in semiconductor handling equipment
Installation tip:
For optimal performance, maintain 0.5-1mm clearance between stopper face and target surface during mounting.
Lubricate with ISO VG32 hydraulic oil before initial operation. Maximum side load capacity: 15N.
| Property | Property Value |
|---|---|
| sku | TTQ20X20SB |
| Port Size | M5×0.8 |
| Magnet | S-Magnetic |
| Bore Diameter | <20mm> |
| Self-locking Function | Non Self-locking |
| Stroke | <20mm> |
| Blocking Method | Flat Cylinder |
