Airtac TTQ Stopper Cylinder TTQ20X20SC
1. Complies with JIS standards;
2. Reinforced piston rod design significantly enhances impact resistance;
3. Fixed mounting height with multiple rod end configurations - Optional hydraulic shock absorber delivers superior cushioning performance;
4. Lever roller mechanism integrates self-locking device that prevents arm rebound and ensures secure obstruction of target objects;
5. Comprehensive series/specification options for flexible integration into diverse applications.
Category: Stop Cylinders , Brand: AirTAC , Series: TTQ
AirTAC TTQ Series Stopper Cylinder TTQ20X20SC Specifications
- Model: TTQ20X20SC
- Type: Double-acting magnetic rodless stopper cylinder
- Bore size: 20mm
- Stroke: 20mm (adjustable)
- Operating pressure: 0.05–0.8 MPa
- Temperature range: -10℃ to 70℃
- Port size: M5x0.8 (standard) / NPT1/8 (optional)
- Buffer type: Adjustable rubber cushion
- Material: Aluminum alloy body / Stainless steel rod
- Seal material: NBR (nitrile rubber)
- Weight: 0.52kg ±5%
- Dimensions: 100mm(L) × 42mm(W) × 28mm(H)
- Repeat accuracy: ±0.5mm
- Max lateral load: 50N
- Protection rating: IP54 (standard) / IP67 (with optional wiper)
- Magnetic sensor compatibility: D-A93 series (sold separately)
High-precision linear stopper with integrated T-slot mounting for automated positioning systems. Features corrosion-resistant anodized surface and dual anti-rotation guides for stable vertical/horizontal operation. Includes shock-absorbing end caps and adjustable stopper force via air pressure regulation. Requires 5μm filtered lubricated air (ISO 8573-1 class 3).
- Conveyor belt product positioning in packaging lines
- PCB board clamping in SMT assembly machines
- Workpiece alignment in CNC loading systems
- Carton height adjustment in palletizing robots
- Precision stop mechanism in automotive part sorting
Installation note:
Mount on flat surface with M4 screws (max torque 1.2N·m).
Lubricate every 500km of travel using ISO VG32 turbine oil.
Avoid side impacts exceeding 30N during operation.
| Property | Property Value |
|---|---|
| sku | TTQ20X20SC |
| Port Size | M5×0.8 |
| Magnet | S-Magnetic |
| Bore Diameter | <20mm> |
| Self-locking Function | Non Self-locking |
| Stroke | <20mm> |
| Blocking Method | Round Type |
