Airtac TTQ Stopper Cylinder TTQ20X20SR
1. Complies with JIS standards;
2. Reinforced piston rod design significantly enhances impact resistance;
3. Fixed mounting height with multiple rod end configurations - Optional hydraulic shock absorber delivers superior cushioning performance;
4. Lever roller mechanism integrates self-locking device that prevents arm rebound and ensures secure obstruction of target objects;
5. Comprehensive series/specification options for flexible integration into diverse applications.
Category: Stop Cylinders , Brand: AirTAC , Series: TTQ
AirTAC TTQ Series Stopper Cylinder TTQ20X20SR Technical Details
- Model: TTQ20X20SR
- Type: Compact single-acting stopper cylinder (spring return)
- Bore size: 20mm
- Stroke: 20mm (±1mm tolerance)
- Operating pressure: 0.15-0.7 MPa
- Cushioning: Adjustable rubber bumper
- Mounting style: Standard base mount (M4 threaded holes)
- Port size: M5x0.8 (dual ports for air connection)
- Temperature range: -10℃ to 70℃
- Body material: Anodized aluminum alloy
- Rod material: Stainless steel (SUS304)
- Seal material: NBR rubber
- Protection rating: IP54 (standard), IP67 optional
- Weight: 0.48kg ±3%
- Dimensions: 80mm(L) × 34mm(W) × 34mm(H) (excluding mounting hardware)
Precision stopper cylinder designed for mechanical positioning and workpiece stopping in automated systems. Features anti-rotation shaft design with ±0.5mm repeat positioning accuracy. Corrosion-resistant construction with built-in guide mechanism prevents lateral deflection during operation. Requires filtered air (5-40μm) with ISO VG32 lubricant recommended.
- Conveyor line product positioning systems
- Robotic arm end effector alignment
- PCB assembly machine component stops
- Automotive part fixture positioning
- Packaging machine gate control
Installation recommendations:
Maintain 0.5-1mm clearance between stopper rod tip and target surface.
For vertical mounting, use auxiliary support brackets. Lubricate monthly
with light machine oil (ISO VG22-32) under continuous operation conditions.
| Property | Property Value |
|---|---|
| sku | TTQ20X20SR |
| Port Size | M5×0.8 |
| Magnet | S-Magnetic |
| Bore Diameter | <20mm> |
| Self-locking Function | Non Self-locking |
| Stroke | <20mm> |
| Blocking Method | Roller Type |
